Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Groupset SLX, Deore -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FSR XC M4 Manipulated Alloy ubing w/ new rocker design, bolt on cable guides, 120mm travel, sealed cartridge pivot bearings, disc only, replaceable rear derailleur hanger
Suspension Fork
Rock Shox Tora 302 SL, 120mm, alloy steer, external rebound and preload adj. w/ LO, S/M"" ""Standard"", L/XL ""Stiff"" Coil spring.
Rear Shock
X Fusion 02RLA, Custom tuned for Specialized, rebound adj. w/lock-out, 7.5x1.75"", 2 bearing upper shock mount
Drivetrain
Rear Derailleur
Shimano RD-M672 SLX Shadow, 9 speed, long cage
Front Derailleur
Shimano Deore, 34.9mm clamp, top swing, bottom pull
Shift Levers
Shimano SL-M531 Deore, trigger
Cassette
Shimano HG-50, 9-speed, 11-34t
Crank
Shimano FC-M442-8, Octalink Spline, replaceable rings w/ alloy outer, S: 170mm, others: 175mm
Bottom Bracket
Shimano BB-ES25, Octalink spline, 68mm x 118mm
Chain
KMC X9, 9-speed w/ reusable Missing Link
Pedals
Specialized, 1pc. alloy body and cage, 9/16""
Wheels
Front Hub
Specialized Hi Lo disc, CNC flange, QR, 32h
Rear Hub
Specialized disc, sealed cartridge bearing, high/low flange w/ OS contact side, 32h
Rims
Specialized RHD, disc, double wall w/ eyelets
Spokes
1.8mm (15g) stainless, black, alloy nipples
Tires
Specialized The Captain Sport, 26x2.2"", 60 TPI, wire bead
Brakes
Brakes
Avid Juicy 3SL full hydraulic, alloy backed brake pads, cleansweep S/M: 185mm, L/XL: 203mm rotor
Brake Levers
Avid Juicy 3 SL Hydraulic
Cockpit
Stem
Specialized adjustable rise, four bolt 31.8mm clamp, 3D forged, S:75mm, M:90mm, L/XL:105mm
Handlebar
Specialized XC low rise, butted alloy, 640mm wide, 8 degree up, 8 degree backsweep
Grips
Specialized thin lock on grip
Headset
1-1/8"" Threadless, loose ball bearings w/ seals, black steel cups
Seat
Saddle
Specialized MTB, 7mm steel rails, 143mm
Seatpost
Specialized 6061 alloy, black, 30.9x350/400mm, setback head, 2-bolt micro adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Top Tube Length | 550 mm | 584 mm | 619 mm | 639 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 394 mm | 445 mm | 483 mm | 534 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1080 mm | 1116 mm | 1153 mm | 1175 mm |
| Bottom Bracket Drop | 8 mm | 8 mm | 8 mm | 8 mm |
| Standover Height | 711 mm | 718 mm | 726 mm | 732 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
FSRxc Comp completes the Specialized Fsrxc model. 10 bikes variations carry this model name so far. Take a sneak peek at all Specialized Fsrxc bikes models from 2009, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
As for the rear shock, this bike has the X Fusion 02RLA model, with a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The FSRxc Comp 2009 bike is equipped with 26″ aluminum wheels when leaving the factory. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The FSRxc Comp has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Specialized FSRxc Comp bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
