Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Fork RockShox Judy Silver TK
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 Aluminum, 148mm thru-axle, tapered head tube, internal cable routing
Suspension Fork
RockShox Judy Silver TK, air spring, 42mm offset, 130mm of travel
Drivetrain
Rear Derailleur
Shimano Deore M5100, SGS, 11-speed
Shift Levers
Shimano Deore, M5100, 11spd
Cassette
Shimano Deore, 11spd, 11-51t
Crank
Stout, forged alloy, 76mm BCD, 30T
Chain
KMC X11EPT, 11-speed, anti-corrosion coating w/ reusable Missing Link™
Wheels
Front Hub
Shimano MT400-B, Centerlock 28h, 15x110 Boost
Rear Hub
Shimano MT400-B, Centerlock 32h, 12x148 Boost
Rims
Stout Trail 27.5, 38mm internal width, disc-specific
Spokes
Stainless, 14g
Tires
Butcher GRID TRAIL, GRIPTON® compound, 2Bliss Ready, 27.5x2.8"
Brakes
Brakes
Shimano BR-MT200, 180/160mm
Cockpit
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebar
Stout Riser, double-butted alloy, 9-degree backsweep, 5-degree upsweep, 15mm rise, 750mm / 780mm width, 31.8mm
Grips
Specialized Trail Grips
Seat
Saddle
Body Geometry Bridge Saddle, steel rails
Seatpost
TranzX Dropper, 30.9mm, XS-S: 100mm, M-XL: 120mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.45 mm | 1.38 mm | 1.34 mm | 1.32 mm |
| Bottom Bracket Height | 315 mm | 315 mm | 315 mm | 315 mm | 315 mm |
| Front Center | 695 mm | 715 mm | 735 mm | 761 mm | 787 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 113 mm | 113 mm | 113 mm | 113 mm | 113 mm |
| Stack | 594 mm | 594 mm | 594 mm | 606 mm | 621 mm |
| Reach | 391 mm | 411 mm | 431 mm | 451 mm | 471 mm |
| Top Tube Length | 564 mm | 584 mm | 604 mm | 628 mm | 652 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 340 mm | 375 mm | 410 mm | 455 mm | 505 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 105 mm | 105 mm | 105 mm | 120 mm | 135 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1111 mm | 1131 mm | 1151 mm | 1177 mm | 1204 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 708 mm | 727 mm | 730 mm | 735 mm | 780 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Fuse 27.5 is part of the Specialized Fuse model. There are 38 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Specialized Fuse 27.5 2020 is the cheapest bike model and costs 1300$. Specialized Fuse Expert 29 2020 is the most expensive one and costs 2400$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2020 for 1300$. If we compare this with the average Trail bike cost we notice that the price is 112.46% lower.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
Specialized Fuse 27.5 2020 bike is equipped with the RockShox Judy Silver TK fork, and has 130mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the Fuse 27.5 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the Fuse 27.5. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
