Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCM
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A1 Premium Aluminum w/ Smooth Welds, Zero Stack 44 head tube, forged post-mount 160mm disc, 141mm QR dropout, alloy replaceable derailleur hanger
Suspension Fork
SR Suntour XCM32, 47mm offset, 110x15mm thru-axle, 120mm of travel
Drivetrain
Rear Derailleur
Shimano Deore, Shadow Plus, GS cage, 10-speed
Shift Levers
Shimano Deore, 10-speed
Cassette
Shimano, 10spd, 11-42t
Crank
Stout, forged alloy, 76mm BCD, Alloy, 28T
Bottom Bracket
Square taper, 73mm, internal bearings
Chain
KMC X10, 10-speed w/ reusable Missing Link™
Pedals
Specialized Dirt
Wheels
Front Hub
Stout, alloy, sealed cartridge bearings, 15x110mm thru-axle, 24h
Rear Hub
Stout, alloy, sealed cartridge bearings, 6-bolt disc, 10-speed freehub, quick-release, 28h
Rims
Stout Trail 27.5, 38mm internal width, disc-specific
Spokes
Stainless, 14g
Tires
Purgatory, GRID casing, GRIPTON® compound, 2Bliss Ready, 27.5 x 3.0"
Brakes
Brakes
Tektro Auriga, hydraulic disc, 180mm
Cockpit
Stem
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Handlebar
Stout Riser, double-butted alloy, 9-degree backsweep, 5-degree upsweep, 15mm rise, 750mm width, 31.8mm
Grips
Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness
Seat
Saddle
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
Seatpost
TransX Dropper, TranzX dropper, internal cable routing, remote lever, 30.9mm, 120mm Travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.58 mm | 1.51 mm | 1.47 mm | 1.44 mm |
| Bottom Bracket Height | 315 mm | 315 mm | 315 mm | 315 mm | 315 mm |
| Front Center | 669 mm | 684 mm | 706 mm | 731 mm | 757 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 101 mm | 101 mm | 101 mm | 101 mm | 101 mm |
| Stack | 619 mm | 619 mm | 624 mm | 638 mm | 652 mm |
| Reach | 378 mm | 393 mm | 413 mm | 433 mm | 453 mm |
| Top Tube Length | 556 mm | 583 mm | 604 mm | 629 mm | 653 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 373 mm | 432 mm | 460 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 95 mm | 95 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1097 mm | 1112 mm | 1133 mm | 1159 mm | 1185 mm |
| Bottom Bracket Drop | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm |
| Standover Height | 726 mm | 757 mm | 789 mm | 812 mm | 846 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Fuse 27.5+ is part of the Specialized Fuse model. Specialized released 38 bikes variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Specialized Fuse 27.5+ 2019 is the most affordable bike of this model and has a price of 1150$. On the other hand, Specialized Fuse Comp Carbon 27.5+ 2019, is the most expensive and costs 3200$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1150$. Comparing the average cost of a Trail bike to this one, you will see that Fuse 27.5+ price is 140.17% lower.
Overview of components
Fork
This bike has the SunTour XCM fork installed. The fork’s travel is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When it comes to wheels, the Fuse 27.5+ bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Specialized Fuse 27.5+ bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
Specialized Fuse 27.5+ comes with a dropper post. Therefore, climbing or descending will be a breeze.
