Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 20" -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
100% Cr-Mo, 21"" TT, MID BB shell, tig welded, double-butted and formed DT/TT/ST, externally relieved integrated HT w/ stamped ""S"" logo, gusseted BB yoke, seat-stay mounted U-brake bosses, integrated seat collar, 3D dropouts for 14mm axle w/ integrated axle tensioners
Suspension Fork
Full Cr-Mo, 1-1/8"" threadless for integrated headset, heat treated Cr-Mo 1pc. CNC steerer, butted 1.8-1.2mm Cr-Mo 1-1/4"" blades, 5mm HT Cr-Mo dropouts for 14mm axle w/ gussets
Drivetrain
Cassette
Joy Tech, 1/2"" x 1/8"" x 10t Cr-Mo, cog driver integrated w/ rear hub
Crank
Fuse SL 2pc. 175mm length, tig welded and heat treated Sanko Cr-Mo arms, hollow 19mm x 152mm 8-spline spindle
Bottom Bracket
Mid BB, 2x cartridge bearing, alloy cone spacers w/ 19mm spindle
Chain
KMC KOOL K-710 SL, 1/2"" x 1/8""
Pedals
Specialized Lo Pro A1, 9/16"", sealed cartridge bearing, alloy platform, removable pins
Wheels
Front Hub
Fuse SL, 36h, 2x sealed cartridge bearing, mid flange, hollow 14mm axle
Rear Hub
Fuse SL, 36h, cassette w/ 10t cog driver, 4x sealed cartridge bearing, mid flange, 14mm hollow axle
Rims
Fuse SL, double wall w/ eyelets
Spokes
2mm (14g) stainless
Tires
Specialized Rhythm Lite Control, 20 x 2.1"", DC, 60TPI, aramid bead
Brakes
Brakes
Tektro FX-15, cold forged, double bushing, linear spring, 15mm offset arms, soft compound pads
Brake Levers
Tektro 275A, cold forged two finger lever, 15mm cable pull
Cockpit
Stem
Fuse SL, forged alloy, 2pc. moto-style clamp, top load, 50mm extension, 1-1/8"" A-Head
Handlebar
Cr-Mo 2pc. 675mm wide, 205mm rise, 12 degree back, 3 degree up sweep
Grips
Fuse Locking Grip, inner clamp on style, Kraton surface, alloy bar ends
Headset
FSA Impact, 1-1/8"" threadless, integrated
Seat
Saddle
Fuse SL, super light foam, hollow 8mm Cr-Mo rail w/ rail brace tube
Seatpost
Alloy, 2 bolt, no offset, 25.4mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 20.5" | 19" | 20" | 21" |
|---|---|---|---|---|---|
| Bottom Bracket Height | 238 mm | 279 mm | 279 mm | 283 mm | 279 mm |
| Rake | 29 mm | 29 mm | 29 mm | 29 mm | 29 mm |
| Seat Tube Angle | 70 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 207 mm | 242 mm | 238 mm | 255 mm | 239 mm |
| Head Tube Angle | 73 ° | 74.25 ° | 74.25 ° | 74.25 ° | 74.25 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 110 mm | 110 mm |
| Chainstay Length | 293 mm | 343 mm | 341 mm | 346 mm | 341 mm |
| Standover Height | 468 mm | 567 mm | 555 mm | 564 mm | 554 mm |
| Wheels | 20" | 20" | 20" | 20" | 20" |
Model Overview
Fuse 4 is part of the Specialized Fuse model. Specialized launched 38 bikes of this model so far. You can easily view all of the Specialized Fuse bikes models from 2010, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
BMX bikes average price
If you want an acceptable BMX bike you should know that the average price is 348$. However, this doesn’t mean that if you spend less money on a BMX bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork material
The fork is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
When it comes to wheels, the Fuse 4 bike is equipped with the 20″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fuse 4 has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
