Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 20" -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hi-Ten frame, STD BB shell, tig welded, formed DT/TT, externally relieved HT w/ stamped ""S"" logo, wrap gusset BB yoke, seat-stay mounted U-brake bosses, integrated seat collar, 6mm dropouts for 14mm axle
Suspension Fork
Specialized 1.6mm Hi-Ten 1-1/4"" blades, 1-1/8"" threadless, 2mm thick Hi-Ten steerer, 6mm dropouts for 14mm axle
Drivetrain
Cassette
Odyssey 1/2"" x 1/8"" x 13t for M30 thread
Crank
Heat Treated Hi Ten 1pc. 165mm
Bottom Bracket
Heat treated Hi-Ten cups, loose ball for 1pc.
Chain
KMC Z-510, 1/2"" x 1/8""
Pedals
Specialized platform, 1/2'' Cr-Mo axle, molded pins
Wheels
Front Hub
Fuse, 36h, sealed mech. mid flange, solid 14mm Cr-Mo axle
Rear Hub
Fuse, 36h, sealed mech. mid flange, 14mm solid axle
Rims
Fuse Single, single wall
Spokes
2mm (14g) stainless
Tires
Specialized Rhythm Lite Sport, 20 x 2.1"", 30TPI, wire bead
Brakes
Brakes
Tektro FX-330, linear spring, 15mm offset arms w/ grey soft compound pads
Brake Levers
Tektro SBL-89, alloy two finger, 16mm cable pull
Cockpit
Stem
Fuse forged alloy, 50mm extension, 1 1/8"" A-Head
Handlebar
Hi-Ten 2pc. 675mm wide, 205mm rise, 12 degree back, 3 degree up sweep
Grips
Specialized File, Kraton w/ flange
Headset
1-1/8"" threadless
Seat
Saddle
7mm rails, front and rear bumpers
Seatpost
Alloy, 2 bolt, no offset, 25.4mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 20.5" | 19" | 20" | 21" |
|---|---|---|---|---|---|
| Bottom Bracket Height | 238 mm | 279 mm | 279 mm | 283 mm | 279 mm |
| Rake | 29 mm | 29 mm | 29 mm | 29 mm | 29 mm |
| Seat Tube Angle | 70 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 207 mm | 242 mm | 238 mm | 255 mm | 239 mm |
| Head Tube Angle | 73 ° | 74.25 ° | 74.25 ° | 74.25 ° | 74.25 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 110 mm | 110 mm |
| Chainstay Length | 293 mm | 343 mm | 341 mm | 346 mm | 341 mm |
| Standover Height | 468 mm | 567 mm | 555 mm | 564 mm | 554 mm |
| Wheels | 20" | 20" | 20" | 20" | 20" |
Model Overview
Fuse Grom 20 belongs to the Specialized Fuse model. Specialized released 38 bikes variations of this model so far. Check out the entire range from 2010 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
BMX bikes average price
According to our calculations, the average cost of a BMX bike that is reliable is 348$. However, even though the average price of a BMX bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Fuse Grom 20 components
Fork material
The fork on this bike is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
The Fuse Grom 20 2010 bike is equipped with 20″ aluminum wheels when leaving the factory. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fuse Grom 20 comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
