Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus, Shimano -
Suspension Rigid -
Drivetrain 2 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Globe A1 Premium Aluminum trekking design, fully manipulated tubing w/ fender and rack braze-ons, integrated kickstand mount, fully integrated rear rack w/ forged dropout and pannier hook
Suspension Fork
Globe Hi-Ten straight-blade steel fork
Drivetrain
Rear Derailleur
Shimano Altus, 7-speed
Front Derailleur
Shimano, top swing, dual pull
Shift Levers
Shimano Alivio Rapidfire, 7-speed
Cassette
Shimano Mega Range, 7-speed, 14-34t
Crank
SR Suntour double ring, w/ alloy crank arm, 170mm
Bottom Bracket
Cartridge bearing, square spindle w/ crank stop right side, capless bolts
Chain
KMC Z7
Pedals
Composite platform body, sealed loose ball bearings
Wheels
Front Hub
Forged alloy, double sealed, ground race, QR
Rear Hub
Freewheel, w/ loose ball bearings, ground race, QR
Rims
Alloy double-wall
Spokes
2mm (14g) stainless
Tires
Specialized Nimbus Sport w/ Flak Jacket protection, 26 TPI, 700x35c
Brakes
Brakes
Alloy linear pull, 1pc. pad
Brake Levers
Die cast ""V""-brake lever, linear pull
Cockpit
Stem
Forged alloy, 4-bolt, 25.4mm, 1-1/8"" w/ 15 degree rise
Handlebar
Alloy, 25.4mm, 31 degree up, 24 degree back sweep
Headset
1-1/8"" threadless, integrated, semi-cartridge Campy style bearings
Seat
Saddle
Globe Haul men's, 175mmmm
Seatpost
Alloy, 2-bolt forged head, 30.9mm, 12.5mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Front Center | 638 mm | 650 | 656 mm | 661 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 78 mm | 78 mm | 74 mm | 71 mm |
| Top Tube Length | 552 mm | 567 mm | 582 mm | 597 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 385 mm | 435 mm | 460 mm | 510 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 70.5 ° |
| Head Tube Length | 140 mm | 170 mm | 200 mm | 230 mm |
| Chainstay Length | 502 mm | 502 mm | 502 mm | 502 mm |
| Wheelbase | 1133 mm | 1145 mm | 1151 mm | 1156 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 713 mm | 749 mm | 775 mm | 820 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Haul 1 completes the Specialized Haul model. Specialized launched 6 bikes of this model so far. Take a sneak peek at all Specialized Haul bikes models from 2012, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Utility bikes
If you want to purchase a solid Utility bike, it is important to know that the average cost is 1069$. However, you could also get a good Utility bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Haul 1 components
Fork material
The fork is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
The wheels on Haul 1 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized Haul 1 is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
Specialized Haul 1 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
