Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alivio, Altus -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Globe A1 Premium Aluminum cargo design, fully manipulated custom tubing w/ fender and rack braze-ons, integrated kickstand mount, fully integreated rear rack w/ forged dropout and pannier hook
Suspension Fork
Globe Haul straight-blade steel fork
Drivetrain
Rear Derailleur
Shimano Alivio, 8-speed
Front Derailleur
Shimano FD-M310, 31.8mm clamp, top swing, dual pull
Shift Levers
Shimano SL-MC40, 8-speed, Rapid Fire
Cassette
SRAM PG-820, 8-speed, 11-32t
Crank
FSA alloy crank arm
Bottom Bracket
Cartridge bearing, square spindle with crank stop right side and capless bolts
Chain
KMC Z8, w/ reusable Missing Link
Pedals
Globe City, Body Geometry, composite w/rubber top, 1.5mm varus wedge
Wheels
Front Hub
Forged alloy, double sealed, ground race, QR, 36h
Rear Hub
Forged alloy, double sealed, ground race, cassette, QR, 36h
Rims
Globe 700c, double wall, 36h w/CNC side wall
Spokes
1.8mm (15g) stainless
Tires
Specialized Nimbus, 700x35c, 60TPI, w/ Flak Jacket protection
Brakes
Brakes
Alloy linear pull, 1pc. pad
Brake Levers
V-Brake, linear pull
Cockpit
Stem
Forged alloy, 4-bolt, 31.8mm, 8 degree rise, including LED top-cap light
Handlebar
Alloy, 31.8mm, 650mm wide, 31 degree up, 24 degree back sweep
Headset
1-1/8"" threadless, integrated, semi-cartridge campy style bearings
Seat
Saddle
Specialized Body Geometry Fitness women's, front and rear bumpers, 155mm width
Seatpost
Alloy, 2-bolt forged head, 12.5mm offset, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Front Center | 628 mm | 640 mm | 646 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 78 mm | 78 mm | 74 mm |
| Top Tube Length | 542 mm | 557 mm | 572 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 385 mm | 435 mm | 460 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° |
| Head Tube Length | 140 mm | 170 mm | 200 mm |
| Chainstay Length | 502 mm | 502 mm | 502 mm |
| Wheelbase | 1123 mm | 1135 mm | 1141 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 605 mm | 614 mm | 619 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Haul 1 Step Through belongs to the Specialized Haul model. There are 6 bikes that carry this model name. You can easily view all of the Specialized Haul bikes models from 2010, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Utility bikes average price
If you want an acceptable Utility bike you should know that the average price is 1069$. However, even if your budget is less than the average, you might still be able to get a top-quality Utility bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Haul 1 Step Through components
Fork material
The fork on this bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
As for the wheels, Specialized Haul 1 Step Through 2010, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized Haul 1 Step Through is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
Specialized Haul 1 Step Through bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
