Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alfine -
Suspension Rigid -
Drivetrain Belt Drive, IGH -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Globe A1 Premium Aluminum cargo design, fully manipulated custom tubing w/ fender and rack braze-ons, integrated kickstand mount
Suspension Fork
Globe Live straight-blade aluminum fork w/ custom forged crown and porteur basket/rack system
Drivetrain
Shift Levers
Shimano Alfine tap fire, 8-speed
Cassette
Gates belt drive cog, 24t
Crank
Sugino EX-1 aluminum, w/ alloy chainguard
Bottom Bracket
Cartridge bearing, square spindle with crank stop right side and capless bolts
Chain
Belt drive, 122 links
Pedals
Classic full alloy pedal
Wheels
Front Hub
Hi Lo flange, loose ball, QR, 36h
Rear Hub
Shimano Alfine internal 8-speed, 36h
Rims
Globe RHD 700c, alloy double wall disc specific, 36h
Spokes
2mm (14g) stainless
Tires
Specialized Infinity Armadillo, 700x32c, 60TPI
Brakes
Brakes
Tektro Auriga Comp, hydraulic dual piston, w/160mm rotors
Brake Levers
Auriga Comp brake levers
Cockpit
Stem
Forged alloy, 2-bolt, 15 degree rise, 25.4mm clamp
Handlebar
Alloy, 25.4mm, 610mm wide, 43 degree up, 57 degree back sweep
Headset
1-1/8"" threadless, integrated, semi-cartridge campy style bearings
Seat
Saddle
Specialized Body Geometry Fitness, 143mm width, front and rear bumpers
Seatpost
Alloy, 2-bolt forged head, 12.5mm offset, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Front Center | 621 mm | 621 mm | 630 mm | 642 mm |
| Rake | 59 mm | 59 mm | 59 mm | 59 mm |
| Trail | 46 mm | 40 mm | 40 mm | 40 mm |
| Top Tube Length | 562 mm | 577 mm | 592 mm | 607 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.25 ° |
| Seat Tube Length | 385 mm | 435 mm | 485 mm | 535 mm |
| Head Tube Angle | 73 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Length | 120 mm | 135 mm | 155 mm | 175 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1070 mm | 1070 mm | 1079 mm | 1091 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 709 mm | 746 mm | 782 mm | 818 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Live 3 completes the Specialized Live model. 10 bikes variations carry this model name so far. You can easily view all of the Specialized Live bikes models from 2010, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Utility bikes
If you want an acceptable Utility bike you should know that the average price is 1069$. However, even if your budget is less than the average, you might still be able to get a top-quality Utility bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Live 3 components
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
When it comes to wheels, the Live 3 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized Live 3 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
