Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Travel Front 80mm -
Fork Marzocchi
-
Suspension Hardtail -
Drivetrain Single Speed -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
P. Series Reynolds 520 Cr-Mo, double-butted TT/DT, externally relieved HT, disc mount, 6mm offset horizontal drop out w/ integrated tensioner system, includes multispeed hardware, disc only
Suspension Fork
Marzocchi DJ3, 80mm, Cr-Mo steerer, 32mm Cr-Mo stanchions, magnesium lower, cold forged crown, fixed rate damping, coil/mcu w/ preload adj. ""stiff"" spring
Drivetrain
Cassette
Single speed, Cr-Mo, 1/8"" x 12t
Crank
Fuse tubular heat treated Cr-Mo 2pc w/ hollow 19mm spindle
Bottom Bracket
Threaded Euro, alloy cups, 4x cartridge bearing, alloy spacers
Chain
KMC Z510HX, 1/2"" x 1/8"", anti-drop inner links
Pedals
SBC Lo-A1, Alloy platform w/ removable pins, 9/16""
Wheels
Front Hub
Forged alloy, machined high/low flange and disc mount, ground race, 36h, nutted 3/8"" axle
Rear Hub
Forged alloy single speed cassette, machined flanges and disc mount, double sealed, ground race, 36h, nutted 3/8"" axle, 1/8"" x 12t cog
Rims
P.Disc AM, double wall disc w/ eyelets, 36h
Spokes
2mm (14g) stainless
Tires
Specialized Rhythm Lite Control, 26x2.3"", 60TPI, aramid bead
Brakes
Brakes
Avid BB5, mechanical disc, 160mm G2 Clean Sweep rotor
Brake Levers
Avid FR-5, alloy, two-finger, linear pull
Cockpit
Stem
SBC Aggro Stem, 3D forged/CNC, 4-bolt, 35mm length
Handlebar
Alloy riser bar, 55mm rise, 680mm wide, 8 degree back sweep, 7 degree up
Grips
Fuse BMX, single compound, closed end, 140mm
Headset
Integrated cartridge bearing, Campy type, 1-1/8"" threadless
Seat
Saddle
Specialized Fuse Lo Pro, 8mm rails, PVC bumpers front and rear
Seatpost
Alloy two bolt, no offset, micro adjust, 25.4mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | LG |
|---|---|
| Stack Reach Ratio | 1.453 mm |
| Bottom Bracket Height | 312 mm |
| Stack | 577 mm |
| Reach | 397 mm |
| Top Tube Length | 595 mm |
| Seat Tube Angle | 71 ° |
| Seat Tube Length | 332 mm |
| Head Tube Angle | 68.5 ° |
| Head Tube Length | 128 mm |
| Chainstay Length | 390 mm |
| Wheelbase | 1049 mm |
| Bottom Bracket Drop | 31 mm |
| Standover Height | 712 mm |
| Wheels | 26" |
| Rider Min Height | 120 cm |
About this model
P.1 completes the Specialized P1 model. Specialized launched 7 bikes of this model so far. You can easily view all of the Specialized P1 bikes models from 2010, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Dirt Jump bikes average price
If you want to purchase a solid Dirt Jump bike, it is important to know that the average cost is 863$. However, even though the average price of a Dirt Jump bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
P.1 components
Fork
The P.1 comes factory-installed with the Marzocchi fork. This has a travel range of 80mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork on this bike is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
The wheels on P.1 are the 26″ aluminum type. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
When you want to stop the bike in time, the brakes are vital. The P.1 has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
