Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset X4, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 Premium Aluminum, tig weld, fully-butted w/ double ORE DT, externally machined HT, forged dropouts w/ replaceable 98954020 hanger, disc only
Suspension Fork
SR Suntour SF9-XCM-V2, 100mm, 1pc. alloy lower, 30mm Hi-Ten stanchions, coil/mcu spring w/ preload adj. spring seals, disc only
Drivetrain
Rear Derailleur
SRAM X-4, midcage
Front Derailleur
Shimano Altus, 34.9mm clamp, bottom swing
Shift Levers
SRAM X-4, 8-speed trigger
Cassette
SRAM PG-820, 8-speed, 11-32t
Crank
SR SunTour, Octalink spline
Bottom Bracket
Shimano BB-ES25, Octalink spline, cartridge bearing, 68mm x 118mm
Chain
KMC X8 w/ reuseable Missing Link
Pedals
Steel cage, composite body, 9/16""
Wheels
Front Hub
Specialized forged alloy, double sealed, ground race, 32h
Rear Hub
Specialized, forged alloy, double sealed, ground race, cassette, QR, 32h
Rims
Specialized/Alex HRD, 26"", pinned, alloy double wall, 32h
Spokes
1.8mm (15g) stainless
Tires
Specialized Resolution Sport, 26 x 2.1"", wire bead, 30TP
Brakes
Brakes
Avid BB5, mechanical disc, caliper/adapter w/ 160mm G2 Clean Sweep rotor
Brake Levers
Specialized linear pull
Cockpit
Stem
Specialized 3D forged, 10 degree rise, 25.4mm clamp
Handlebar
Specialized alloy riser bar, 25.4mm, 38mm rise, 640mm wide, 8 degree back sweep, 8 degree up
Grips
Specialized dual compound Kraton, no flange, 130mm
Headset
Specialized 1-1/8"" threadless, loose ball
Seat
Saddle
Specialized BG All Mountain, 143mm wide, front and rear bumpers
Seatpost
Specialized alloy two bolt, no offset, micro adjust, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 12" | 15" | 17" | 19" | 21" | 24" |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm |
| Top Tube Length | 542 mm | 572 mm | 597 mm | 622 mm | 647 mm | 672 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 305 mm | 381 mm | 432 mm | 483 mm | 533 mm | 610 mm |
| Head Tube Angle | 69 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1035 mm | 1056 mm | 1082 mm | 1107 mm | 1133 mm | 1159 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Standover Height | 687 mm | 739 mm | 775 mm | 807 mm | 840 mm | 887 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" |
Model Overview
P.1 All Mountain Disc is a Specialized P1 model. Specialized launched 7 bikes of this model so far. Take a sneak peek at all Specialized P1 bikes models from 2009, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Dirt Jump bikes
According to our calculations, the average cost of a Dirt Jump bike that is reliable is 863$. However, even if your budget is less than the average, you might still be able to get a top-quality Dirt Jump bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
P.1 All Mountain Disc components
Fork
The P.1 All Mountain Disc comes factory-installed with the SunTour XCM fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
The P.1 All Mountain Disc 2009 bike is equipped with 26″ aluminum wheels when leaving the factory. Being a little smaller, these wheels will fit both small and tall riders. However, they provide less traction than 29″ wheels do.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized P.1 All Mountain Disc is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
