Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset X4, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
P. Series AM A1 Premium Aluminum, tig weld, fully-butted w/ double ORE DT, externally machined HT, forged dropouts w/ replaceable hanger, disc only
Suspension Fork
SR Suntour SF10-XCM, 100mm (12"" only = 80mm), 1pc. alloy lower, 30mm Hi-Ten stanchions, coil/mcu spring w/ preload adj. size-specific spring rates, spring seals, disc only
Drivetrain
Rear Derailleur
SRAM X-4, midcage
Front Derailleur
Shimano Altus, 34.9mm clamp
Shift Levers
SRAM X4-R 8sp trigger
Cassette
SRAM PG-820, 8-speed, 11-32t
Crank
SR SunTour XCM fully replaceable, Octalink spline
Bottom Bracket
Shimano BB-ES25, Octalink spline, cartridge bearing, 68mm x 118mm
Chain
KMC X8 w/ reuseable Missing Link
Pedals
Steel cage, composite body, 9/16""
Wheels
Front Hub
Forged alloy, hi/low flange, double sealed, ground race, machined disc mount, 32h
Rear Hub
Forged alloy cassette, machined flanges and disc mount, double sealed, ground race, 32h, QR type
Rims
P.Disc AM, double wall disc, 32h
Spokes
2mm (14g) stainless
Tires
Specialized The Captain Sport, 26 x 2.2"", 60TPI, wire bead
Brakes
Brakes
Avid BB5, mechanical disc, 160mm G2 Clean Sweep rotor
Brake Levers
Alloy, linear pull
Cockpit
Stem
3D forged alloy, 10 degree rise, 25.4mm clamp
Handlebar
Alloy riser bar, 25.4mm, 38mm rise, 640mm wide, 8 degree back sweep, 8 degree up
Grips
Specialized Enduro, dual compound Kraton, no flange, 131mm
Headset
1-1/8"" threadless, loose ball
Seat
Saddle
Specialized XC, Body Geometry, 143mm width, front and rear bumpers
Seatpost
Alloy two bolt, 12.5mm offset, micro adjust, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 12" | 15" | 17" | 19" | 21" | 24" |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm |
| Top Tube Length | 542 mm | 572 mm | 597 mm | 622 mm | 647 mm | 672 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 305 mm | 381 mm | 432 mm | 483 mm | 533 mm | 610 mm |
| Head Tube Angle | 69 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1035 mm | 1056 mm | 1082 mm | 1107 mm | 1133 mm | 1159 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Standover Height | 687 mm | 739 mm | 775 mm | 807 mm | 840 mm | 887 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" |
About this model
P.1 All Mountain Disc completes the Specialized P1 model. Specialized launched 7 bikes of this model so far. Check out the entire range from 2010 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Dirt Jump bikes
According to our math, the average price for a trustworthy Dirt Jump bike is 863$. However, even though the average price of a Dirt Jump bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The fork installed on this bike is the SunTour XCM model. The travel on this model is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
P.1 All Mountain Disc has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
As for the wheels, Specialized P.1 All Mountain Disc 2010, has a 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
