Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A1 Premium Aluminum, Sport Trail 27.5 Geometry, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger
Suspension Fork
SR SunTour XCE 28, Rx Tune, coil spring, 42mm offset, 80/100mm of travel (size-specific)
Drivetrain
Rear Derailleur
Shimano Tourney TX, 8-speed
Front Derailleur
Shimano Tourney FD-TY710
Shift Levers
Shimano EF505, hydraulic, 2x8-speed
Cassette
Sunrace, 8-speed, 11-34t
Crank
Stout 2x, forged alloy, 36/22T
Bottom Bracket
Square-tapered, 73mm, internal bearings
Chain
KMC X8 EPT, anti-rust coating, 8-speed w/ reusable Missing Link™
Wheels
Front Hub
Shimano, Center Lock™ disc, 9x100mm spacing, quick-release, 32h
Rear Hub
Shimano FH-TX505, Center Lock™ disc, 9x135mm spacing, quick-release, 32h
Rims
Specialized alloy, disc only, double-wall, 25mm inner width, 32h
Spokes
Stainless, 14g
Tires
Ground Control Sport, 27.5x2.3"
Brakes
Brakes
Shimano BR-MT200, hydraulic disc
Cockpit
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebar
Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Grips
Specialized MTB Grip, lock-on
Seat
Seatpost
Alloy, 12mm offset, 2-bolt clamp, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.41 mm | 1.4 mm | 1.38 mm | 1.35 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 631 mm | 651 mm | 680 mm | 708 mm | 733 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 94 mm | 94 mm | 94 mm | 94 mm | 94 mm |
| Stack | 557 mm | 557 mm | 580 mm | 599 mm | 613 mm |
| Reach | 375 mm | 395 mm | 415 mm | 435 mm | 455 mm |
| Top Tube Length | 537 mm | 567 mm | 594 mm | 620 mm | 644 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 310 mm | 360 mm | 415 mm | 450 mm | 510 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 95 mm | 95 mm | 100 mm | 120 mm | 135 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1058 mm | 1078 mm | 1107 mm | 1134 mm | 1160 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Standover Height | 655 mm | 685 mm | 734 mm | 761 mm | 803 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Pitch 27.5 is part of the Specialized Pitch model. Specialized launched 36 bikes of this model so far. You can easily view all of the Specialized Pitch bikes models from 2021, here.
Model range prices
Specialized Pitch 27.5 2021 is the most economical model, with a starting price of 485$. Specialized Pitch Sport 2021 on the other hand costs 577$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2021 for 485$. In conclusion, this bike price is 292.78% lower than the price of the average Crosscountry bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
Specialized Pitch 27.5 2021 bike is equipped with the Suntour fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on Pitch 27.5 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Pitch 27.5 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
