Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A1 Premium Aluminum, Sport Trail 27.5 Geometry, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger
Suspension Fork
SR SunTour XCT 30 w/ MCD lock out, Rx Tune, coil spring, 42mm offset, 80/90/100mm of travel of (size-specific)
Drivetrain
Rear Derailleur
Shimano Acera, 8-speed
Front Derailleur
Shimano Altus FD-M315
Shift Levers
Shimano EF505, hydraulic, 8-speed
Cassette
Sunrace, 8-speed, 11-34t
Crank
Stout 2x, forged alloy, 36/22T
Bottom Bracket
Square-tapered, 73mm, internal bearings
Chain
KMC X8 EPT, anti-rust coating, 8-speed w/ reusable Missing Link™
Wheels
Front Hub
Shimano, Center Lock™ disc, 9x100mm spacing, quick-release, 32h
Rear Hub
Shimano FH-TX505, Center Lock™ disc, 9x135mm spacing, quick-release, 32h
Rims
Stout Trail 27.5, alloy, disc-specific, double-wall, 25mm internal width, 32h
Spokes
Stainless, 14g
Tires
Ground Control Sport, 60 TPI, wire bead, Flak Jacket Flat protection, 27.5 x 2.3"
Brakes
Brakes
Shimano BR-MT200, hydraulic disc, 160/180mm
Cockpit
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebar
Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Grips
Specialized MTB Grip, lock-on
Seat
Seatpost
Alloy, 12mm offset, 2-bolt clamp, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.41 mm | 1.4 mm | 1.38 mm | 1.35 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 631 mm | 651 mm | 680 mm | 708 mm | 733 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 94 mm | 94 mm | 94 mm | 94 mm | 94 mm |
| Stack | 557 mm | 557 mm | 580 mm | 599 mm | 613 mm |
| Reach | 375 mm | 395 mm | 415 mm | 435 mm | 455 mm |
| Top Tube Length | 537 mm | 567 mm | 594 mm | 620 mm | 644 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 310 mm | 360 mm | 415 mm | 450 mm | 510 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 95 mm | 95 mm | 100 mm | 120 mm | 135 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1058 mm | 1078 mm | 1107 mm | 1134 mm | 1160 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Standover Height | 655 mm | 685 mm | 734 mm | 761 mm | 803 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Pitch Sport belongs to the Specialized Pitch model. Specialized released 36 bikes variations of this model so far. You can easily view all of the Specialized Pitch bikes models from 2020, here.
Model range prices
Specialized Pitch 27.5 2020 is the most affordable bike of this model and has a price of 520$. On the other hand, Specialized Pitch Expert 1X 2020, is the most expensive and costs 875$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2020 and its price was 640$. Doing a quick comparison, we notice that Pitch Sport price is 197.66% smaller than the average cost of a Crosscountry bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Pitch Sport components
Fork
The Pitch Sport comes factory-installed with the SunTour XCT fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, Specialized Pitch Sport 2020, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Pitch Sport has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
