Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 Premium Aluminum, Sport Trail 650b Geometry, butted tube sets, externally relieved head tube, forged dropouts, reinforced disc mount, replaceable alloy derailleur hanger
Suspension Fork
SR Suntour XCM 650b, coil spring, custom Multi-Circuit Damping, 80/100mm of travel (size specific)
Drivetrain
Rear Derailleur
Shimano Alivio, Shadow design, SGS cage
Front Derailleur
Shimano Altus, 34.9mm clamp, down-swing
Shift Levers
Shimano Altus, 8-speed
Cassette
Sunrace, 8-speed, 11-34t
Crank
Stout, forged alloy construction, 44/32/22T
Bottom Bracket
Square taper, 73mm, internal bearings
Chain
KMC X8, 8-speed w/reusable MissingLink
Pedals
Specialized Dirt
Wheels
Front Hub
Shimano Center Lock, disc, 9x100mm QR, 32h
Rear Hub
Shimano Center Lock, disc, 10x135mm QR, 32h
Rims
Stout 650b, alloy, disc only, double-wall, 25mm inner width, 32h
Spokes
Stainless, 14g
Tires
Ground Control Sport, 650bx2.1"", 60TPI, wire bead, Flak Jacket protection
Brakes
Brakes
Shimano BR-M315, hydraulic disc, resin pads
Cockpit
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebar
Stout bar, 15mm rise, 9-degree backsweep, 5-degree upsweep, 720mm width, 31.8mm
Grips
Specialized MTB Grip, lock-on
Seat
Saddle
Body Geometry mountain, steel rails, 143mm
Seatpost
Alloy, 12mm offset, 2-bolt clamp, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.49 mm | 1.42 mm | 1.35 mm | 1.34 mm |
| Bottom Bracket Height | 301 mm | 301 mm | 301 mm | 301 mm | 301 mm |
| Front Center | 605 mm | 626 mm | 645 mm | 664 mm | 690 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 79 mm | 79 mm | 79 mm | 79 mm | 79 mm |
| Stack | 578 mm | 578 mm | 578 mm | 578 mm | 597 mm |
| Reach | 368 mm | 389 mm | 408 mm | 427 mm | 447 mm |
| Top Tube Length | 534 mm | 555 mm | 585 mm | 604 mm | 630 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 394 mm | 444 mm | 460 mm | 510 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 100 mm | 120 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1023 mm | 1044 mm | 1063 mm | 1082 mm | 1108 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 692 mm | 731 mm | 778 mm | 790 mm | 833 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Pitch Sport 650b belongs to the Specialized Pitch model. There are 36 bikes that carry this model name. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Pitch Sport 650b components
Fork
This bike has the SunTour XCM fork installed. The fork’s travel is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the Pitch Sport 650b model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized Pitch Sport 650b is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
