Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized FACT 9r carbon, FACT construction, Women's Endurance Geometry and layup, Zertz, OSBB
Suspension Fork
Specialized Ruby, FACT carbon full monocoque, Zertz
Drivetrain
Rear Derailleur
Shimano 105, 10-speed, long cage
Front Derailleur
Shimano 105, braze-on, 10-speed
Shift Levers
Shimano 105 STI, 10-speed
Cassette
Shimano Tiagra, 10-speed, 12-30
Crank
FSA Gossamer Pro, BB30
Bottom Bracket
OS integrated, sealed bearings
Chain
KMC X10
Pedals
Nylon flat test ride, loose ball, w/ reflectors
Wheels
Rims
Fulcrum S5
Tires
Specialized Espoir Elite, 60TPI, foldable aramid bead, double BlackBelt protection, 700x25c
Brakes
Brakes
Shimano 105
Brake Levers
Shimano 105
Cockpit
Stem
Specialized Expert Pro-Set, 3D forged aluminum, 4-position adjustable, 4-bolt, 31.8mm clamp
Handlebar
Specialized Women's Comp, alloy, 123mm drop, 75mm reach
Headset
1-1/8"" Cr-Mo cartridge bearings, 20mm cone spacer, w/ 20mm of spacers
Seat
Saddle
Body Geometry Women's Lithia Comp Gel, hollow Cr-Mo rails, 143mm
Seatpost
Specialized Comp, carbon, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 48cm | 51cm | 54cm | 57cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.44 mm | 1.48 mm | 1.52 mm | 1.52 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 263 mm | 264 mm |
| Front Center | 577 mm | 584 mm | 587 mm | 591 mm | 614 mm |
| Rake | 51 mm | 51 mm | 51 mm | 49 mm | 49 mm |
| Trail | 68 mm | 62 mm | 60 mm | 59 mm | 59 mm |
| Stack | 515 mm | 528 mm | 543 mm | 565 mm | 587 mm |
| Reach | 355 mm | 367 mm | 367 mm | 371 mm | 387 mm |
| Top Tube Length | 506 mm | 519 mm | 526 mm | 536 mm | 563 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 363 mm | 391.5 mm | 421.5 mm | 456.5 mm | 486.5 mm |
| Head Tube Angle | 70.25 ° | 71.25 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm | 165 mm | 190 mm |
| Chainstay Length | 409 mm | 412 mm | 412 mm | 412 mm | 414 mm |
| Wheelbase | 974 mm | 985 mm | 988 mm | 992 mm | 1018 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm | 71 mm |
| Standover Height | 699 mm | 718 mm | 737 mm | 765 mm | 789 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Ruby Elite Compact EQ completes the Specialized Ruby model. There are 78 bikes that carry this model name. Check out the entire range from 2014 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Endurance bikes
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Ruby Elite Compact EQ components
Fork material
Ruby Elite Compact EQ has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the Ruby Elite Compact EQ model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Ruby Elite Compact EQ comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
