Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized FACT 8r carbon, Az1 construction, Designs for Women compact design, Zertz Inserts
Suspension Fork
Specialized FACT carbon, monocoque construction, full carbon legs, crown and steerer w/ Zertz inserts
Drivetrain
Rear Derailleur
Shimano Ultegra SL, short cage
Front Derailleur
Shimano Ultegra SL, 34.9mm clamp, bottom pull
Shift Levers
Shimano Ultegra SL, 10-speed STI, flight deck compatible
Cassette
Shimano Ultegra, 10-speed, 12-27t
Crank
Shimano Ultegra SL
Bottom Bracket
Shimano Ultegra SL, Hollowtech II
Chain
Shimano Ultegra, 10-speed
Pedals
Silver cage, black body, w/ toe clip and strap
Wheels
Front Hub
Shimano Ultegra SL, QR
Rear Hub
Shimano Ultegra SL, alloy cassette, QR
Rims
Shimano Ultegra SL
Spokes
Stainless bladed
Tires
Specialized All Condition Pro, 700x23c, aramid bead, 120TPI w/ Flak Jacket
Brakes
Brakes
Shimano Ultegra SL
Brake Levers
Shimano Ultegra SL, 10-speed STI, flight deck compatible
Cockpit
Stem
Specialized Pro-Set, 3D forged alloy, 4-bolt 31.8mm bar clamp, 4- position adjustable
Handlebar
Specialized Womens, 2014 alloy, short-reach drop, ergonomic shaping, 31.8mm
Headset
Specialized Campy style, 1-1/8"" integrated threadless, sealed stainless steel cartridge bearings, 20mm carbon cone w/ one 10mm and two 5mm carbon spacers
Seat
Saddle
Body Geometry Ruby Women's, carbon reinfoced base, hollow Ti rails, microfiber cover
Seatpost
Specialized Pro SL, FACT carbon w/ Zertz insert, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 56cm | 54cm | 51cm | 48cm | 44cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 0.91 mm | 0.89 mm | 0.87 mm | 0.85 mm | 0.8 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 265 mm | 265 mm |
| Stack | 491 mm | 471 mm | 441 mm | 421 mm | 391 mm |
| Reach | 539 mm | 528 mm | 509 mm | 497 mm | 487 mm |
| Seat Tube Angle | 59 ° | 59 ° | 59 ° | 62 ° | 66 ° |
| Seat Tube Length | 408 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Head Tube Length | 172.5 mm | 170 mm | 170 mm | 165 mm | 165 mm |
| Wheelbase | 411 mm | 391 mm | 391 mm | 371 mm | 371 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 71 mm | 70 mm |
| Standover Height | 91 mm | 91 mm | mm | mm | mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Ruby Expert Compact completes the Specialized Ruby model. There are 78 bikes that carry this model name. Take a sneak peek at all Specialized Ruby bikes models from 2009, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Endurance bikes average price
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork material
Ruby Expert Compact has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The Ruby Expert Compact 2009 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Ruby Expert Compact has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
