Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works FACT 11r carbon, disc-specific, 1-3/8"" lower bearing, OSBB
Suspension Fork
Specialized FACT carbon
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2, 11-speed
Front Derailleur
Shimano Dura-Ace Di2, 11-speed, braze-on
Shift Levers
Shimano 785 Di2, 11-speed
Cassette
Shimano Dura-Ace, 11-speed, 11-28
Crank
S-Works FACT carbon, OSBB, 46/36, w/ CeramicSpeed ceramic bearings
Chain
Shimano Dura-Ace, 11-speed
Pedals
Nylon flat test ride, loose-ball, w/ reflectors
Wheels
Rims
Roval Control SL CX SCS, carbon
Tires
Specialized Terra Pro, 60TPI, 2Bliss Ready, folding bead, 700x33c
Brakes
Brakes
Shimano 785, hydraulic disc, Ice Tech resin pads w/ fins
Cockpit
Stem
S-Works SL, alloy, 4-bolt
Handlebar
Specialized Comp, shallow drop, alloy, 125mm drop, 70mm reach
Headset
1-1/8"" upper, 1-3/8” lower, light alloy housing, stainless steel bearings, 8mm carbon cone spacer, w/ 25mm of carbon spacers
Seat
Saddle
Body Geometry Phenom Expert, hollow Ti rails, 143mm
Seatpost
Specialized CG-R, FACT carbon, single bolt, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.47 mm | 1.49 mm | 1.52 mm | 1.54 mm | 1.57 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 273 mm | 275 mm | 275 mm | 277 mm | 277 mm |
| Front Center | 593 mm | 593 mm | 595 mm | 601 mm | 606 mm | 609 mm | 615 mm |
| Rake | 51 mm | 51 mm | 51 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 75 mm | 69 mm | 62 mm | 64 mm | 61 mm | 58 mm | 55 mm |
| Stack | 524 mm | 542 mm | 556 mm | 568 mm | 585 mm | 599 mm | 620 mm |
| Reach | 368 mm | 371 mm | 378 mm | 381 mm | 386 mm | 389 mm | 395 mm |
| Top Tube Length | 512 mm | 518 mm | 539 mm | 550 mm | 562 mm | 572 mm | 589 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm | 600 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 71.5 ° | 71.5 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 100 mm | 115 mm | 125 mm | 140 mm | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1010 mm | 1009 mm | 1011 mm | 1018 mm | 1024 mm | 1027 mm | 1033 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 766 mm | 784 mm | 797 mm | 811 mm | 827 mm | 843 mm | 864 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
S-Works CruX Di2 is a Specialized Crux model. Specialized launched 94 bikes of this model so far. Check out the entire range from 2015 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Cyclocross bikes
According to our calculations, the average cost of a Cyclocross bike that is reliable is 2012$. However, you could also get a good Cyclocross bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the S-Works CruX Di2 model has 700c carbon wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
