Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset RED 22 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works FACT 11r carbon, disc-specific, 1-3/8"" lower bearing, OSBB
Suspension Fork
Specialized FACT carbon, disc-specific monocoque fork, carbon steerer and crown for 1-3/8"" lower bearing
Drivetrain
Rear Derailleur
SRAM RED 22, 11-speed
Front Derailleur
SRAM RED 22, braze-on, 11-speed, YAW compatible, chain spotter
Shift Levers
SRAM RED 22, DoubleTap, 11-speed, integrated hydraulic brake system
Cassette
SRAM RED 22, 11-speed, 11-28
Crank
S-Works FACT carbon, OSBB
Bottom Bracket
OS integrated, CeramicSpeed sealed ceramic bearings
Chain
SRAM RED 22 w/ PowerLock
Pedals
Nylon flat test ride, loose ball, w/ reflectors
Wheels
Rims
Roval Rapide CLX 40 carbon disc tubular, w/ center lock hub, CeramicSpeed bearings
Tires
Specialized Terra Tubular, 260TPI, 700x33c
Brakes
Brakes
SRAM RED, hydraulic disc, SRAM XX 160mm center-lock rotor
Cockpit
Stem
S-Works SL, 3D forged 7050 aluminum, 4-bolt, 31.8mm clamp
Handlebar
Specialized CX Comp Shallow Bend, 6061 alloy, 125mm drop, 70mm reach
Headset
1-1/8"" upper and 1-3/8"" lower hybrid cartridge lightweight bearings
Seat
Saddle
Body Geometry Phenom Expert, hollow Ti rails, 143mm
Seatpost
S-Works FACT carbon CG-R, single bolt, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.47 mm | 1.5 mm | 1.52 mm | 1.54 mm | 1.57 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 273 mm | 275 mm | 275 mm | 277 mm | 277 mm |
| Front Center | 593 mm | 593 mm | 595 mm | 601 mm | 606 mm | 609 mm | 615 mm |
| Rake | 51 mm | 51 mm | 51 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 75 mm | 69 mm | 62 mm | 64 mm | 61 mm | 58 mm | 55 mm |
| Stack | 524 mm | 543 mm | 556 mm | 569 mm | 585 mm | 599 mm | 620 mm |
| Reach | 368 mm | 371 mm | 377 mm | 380 mm | 386 mm | 389 mm | 394 mm |
| Top Tube Length | 503 mm | 515 mm | 539 mm | 551 mm | 562 mm | 572 mm | 589 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm | 600 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 71.5 ° | 71.5 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 100 mm | 115 mm | 125 mm | 140 mm | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1010 mm | 1009 mm | 1011 mm | 1018 mm | 1024 mm | 1027 mm | 1033 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 727 mm | 756 mm | 775 mm | 792 mm | 809 mm | 827 mm | 851 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
S-Works CruX Red Disc belongs to the Specialized Crux model. 94 bikes variations carry this model name so far. You can easily view all of the Specialized Crux bikes models from 2014, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Cyclocross bikes
Our math shows that the average cost of a dependable Cyclocross bike is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
S-Works CruX Red Disc components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the S-Works CruX Red Disc bike is equipped with the 700c carbon model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The S-Works CruX Red Disc comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
