Specialized S-Works Diverge STR 2024
2024 Road
Estimate price |
16,057$
Weight | 8.88 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Travel Front 20mm -
Travel Rear 30mm -
Fork Specialized Future Shock
-
Groupset X01 Eagle, RED AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
49cm
155cm - 164cm
52cm
161cm - 171cm
54cm
169cm - 178cm
56cm
175cm - 181cm
58cm
179cm - 189cm
61cm
187cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works Diverge FACT 11r carbon frameset with front and rear Future Shock suspension, SWAT™ Door integration, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc
Suspension Fork
Future Shock 3.3 w/ Damper, Smooth Boot, FACT carbon, 12x100 mm thru-axle, flat-mount
Drivetrain
Rear Derailleur
SRAM XG-1295 Eagle, 12-speed, 10-50t
Shift Levers
SRAM Red eTap AXS
Cassette
SRAM XX1 Eagle AXS
Crank
SRAM Red 1 AXS, 40T
Bottom Bracket
SRAM DUB BSA 68
Chain
SRAM XX1 Eagle, 12-speed
Wheels
Rims
Front: Roval Terra CLX II, 25mm internal width, 32mm depth, 21h, Tubeless ready, Roval LFD hub with ceramic SINC bearings, Centerlock disc, DT Swiss Aerolite spokes, Rear: Roval Terra CLX II, 25mm internal width, 32mm depth, 24h, Tubeless ready, Roval LFD hub with ceramic SINC bearings, Centerlock disc, DT Swiss Aerolite spokes
Tires
Front: Tracer Pro 2BR, 700x42, Rear: Tracer Pro 2BR, 700x42
Brakes
Brakes
Front: SRAM Red eTap AXS, hydraulic disc, 160mm CenterLine XR rotor, Rear: SRAM Red eTap AXS, hydraulic disc, 160mm CenterLine XR rotor
Cockpit
Stem
S-Works Future Stem w/ Integrated Computer mount
Handlebar
Roval Terra, carbon, 103mm drop x 70mm reach x 12º flare
Seat
Saddle
Body Geometry S-Works Power with Mirror, carbon fiber rails, carbon fiber base
Seatpost
S-Works Carbon Seat Post, 20mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.559 mm | 1.54 mm | 1.548 mm | 1.554 mm | 1.579 mm | 1.607 mm |
| Bottom Bracket Height | 270 mm | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 607 mm | 612 mm | 619 mm | 629 mm | 645 mm | 663 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 69 mm | 66 mm | 61 mm | 57 mm | 57 mm | 57 mm |
| Stack | 569 mm | 576 mm | 593 mm | 609 mm | 633 mm | 659 mm |
| Reach | 365 mm | 374 mm | 383 mm | 392 mm | 401 mm | 410 mm |
| Top Tube Length | 527 mm | 540 mm | 556 mm | 570 mm | 586 mm | 602 mm |
| Seat Tube Angle | 74.5 ° | 74.25 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71.25 ° | 71.75 ° | 71.75 ° | 71.75 ° |
| Head Tube Length | 100 mm | 100 mm | 115 mm | 130 mm | 155 mm | 182 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1023 mm | 1027 mm | 1034 mm | 1044 mm | 1060 mm | 1078 mm |
| Bottom Bracket Drop | 80 mm | 85 mm | 85 mm | 85 mm | 85 mm | 85 mm |
| Standover Height | 704 mm | 730 mm | 753 mm | 778 mm | 804 mm | 833 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 169 cm | 175 cm | 179 cm | 187 cm |
| Rider Max Height | 164 cm | 171 cm | 178 cm | 181 cm | 189 cm | 196 cm |
About this model
S-Works Diverge STR is a Specialized Diverge Str model. There are 13 bikes that carry this model name. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Specialized Diverge STR Comp 2024 is the most affordable bike of this model and has a price of 5295$. On the other hand, Specialized S-Works Diverge STR 2024, is the most expensive and costs 14825$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2024 for 14825$. Comparing this to the average Gravel bike price, we see that the price is 502.15% higher.
Average weight for Gravel bikes
The average weight for Gravel bikes is 8.13 kg (17.92 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
S-Works Diverge STR weighs 8.88 kg (19.58 lbs) and is a bit heavier than the average. In short, the average Gravel bike weight is 9.23% lower than this one.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
Specialized S-Works Diverge STR 2024 bike is equipped with the Specialized Future Shock fork, and has 20mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
S-Works Diverge STR has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Rear Shock
Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The wheels on S-Works Diverge STR are the 700c carbon type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Specialized S-Works Diverge STR has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Specialized S-Works Diverge STR bike has 6 sizes, in the range of 155 cm – 196 cm (5.09 ft – 6.43 ft). In conclusion, finding one for you shouldn’t be a problem.
