Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 160mm -
Travel Rear 165mm -
Fork RockShox Pike RCT3
-
Groupset XX1 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT IS-X 11m carbon front triangle, M5 rear triangle, tapered headtube, PF30 BB, ISCG '05 mounts, internal Command Post IR routing, 142+ dropouts, full cartridge bearing pivots, replaceable derailleur hanger, 165mm travel
Suspension Fork
RockShox Pike RCT3, Solo Air spring, tapered alloy steerer, comp, lockout, reb, and threshold adj. 15mm thru-axle, 160mm travel
Rear Shock
Custom Cane Creek Double Barrel Air, high/low speed comp and reb adj. climb switch, 215.9mm x 57.2mm
Drivetrain
Rear Derailleur
SRAM XX1 Type 2, 11-speed, mid cage
Shift Levers
SRAM XX1, 11-speed, carbon/aluminum trigger, w/ MatchMaker clamp
Cassette
SRAM XX1, 11-speed, 10-42
Crank
SRAM XX1, carbon arms, custom SRAM XX1 style ring, PF30 spindle, S: 170mm, Others: 175mm
Bottom Bracket
SRAM PF30, OS press-in bearings, sealed cartridge
Chain
SRAM XX1, 11-speed, hollow plates/pins, PowerLink
Wheels
Front Hub
Roval Traverse SL, 15mm thru-axle end caps, 27h
Rear Hub
Roval Traverse SL 142+, DT Swiss Star Ratchet, XX1 driver body, 12mm thru-axle, 32h
Rims
Roval Traverse SL, carbon disc, 22mm internal width, 27h/32h
Spokes
DT Swiss Super Comp, 2.0/1.65/1.8 stainless
Tires
Specialized Butcher Control, 2Bliss Ready, 26x2.3"", foldable aramid bead, 60TPI
Brakes
Brakes
Custom Avid X0 Trail, 4-piston caliper, steel backed metallic pad, 200mm rotor
Brake Levers
Custom Avid X0, hydraulic disc, carbon blade w/ bearing, tool-less reach adj. w/ MatchMaker clamp
Cockpit
Stem
Syntace F109, 6-degree rise, 31.8mm clamp
Handlebar
Specialized All-Mountain, low-rise 7050 alloy, 750mm wide, 8-degree backsweep, 6-degree upsweep, 31.8mm
Grips
Specialized Sip Grip, light lock-on, half-waffle aramid-infused, S/M: regular, Others: XL thickness
Headset
1-1/8 and 1-1/2"" threadless, Campy style upper with 1-1/2"" lower, cartridge bearings
Seat
Saddle
Body Geometry Henge Expert, Ti rails, 143mm
Seatpost
Specialized Command Post IR, 3-position, internally routed adjustable height w/ air spring, remote operated, single bolt head, 30.9mm, S:100mm, Others: 125mm travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.34 mm | 1.28 mm |
| Bottom Bracket Height | 351 mm | 351 mm | 351 mm |
| Stack | 563 mm | 573 mm | 581 mm |
| Reach | 400 mm | 427 mm | 453 mm |
| Top Tube Length | 554 mm | 584 mm | 613 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 396 mm | 430 mm | 468 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm |
| Wheelbase | 1117 mm | 1149 mm | 1179 mm |
| Bottom Bracket Drop | -8 mm | -8 mm | -8 mm |
| Standover Height | 753 mm | 756 mm | 765 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
S-Works Enduro is a Specialized Enduro model. There are 117 bikes that carry this model name. Take a sneak peek at all Specialized Enduro bikes models from 2014, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
S-Works Enduro components
Fork
The RockShox Pike RCT3 is included from the factory. It has a travel distance of 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
The S-Works Enduro has a rear shock with a travel of 165mm. The model Custom Cane Creek Double Barrel Air is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The S-Works Enduro 2014 bike is equipped with 26″ carbon wheels when leaving the factory. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. Specialized S-Works Enduro has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
S-Works Enduro comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
