Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 120mm -
Travel Rear 160mm -
Fork Fox Float 36
-
Groupset XX, X0 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT IS-X 10m carbon front triangle, M5 rear triangle, tapered HT, replaceable ISCG mounts, 142mm dropouts, full cartridge bearing pivots, replaceable derailleur hanger, 160mm travel
Suspension Fork
Fox 36 TALAS RLC, Kashima stanchions, tapered alloy steerer, comp and LO and reb adj. 20mm thru-axle, 160/120mm adjustable travel
Rear Shock
Fox RP23 Adaptive Logic, Kashima coating, with Boost Valve, reb and separate climbing setting, custom 3-position open comp adj. 8.5x2.125""
Drivetrain
Rear Derailleur
SRAM XX, 10-speed, mid cage
Front Derailleur
SRAM X0, 10-speed, S1 direct mount for DMD, bottom-pull
Shift Levers
SRAM X0, 10-speed, carbon/aluminum trigger, w/MatchMaker clamp
Cassette
SRAM XX 10-speed, 11-36t
Crank
SRAM X0 Carbon, 10-speed AM double, GXP spindle, removable spider, Gamut shiftguide, S: 170mm, others: 175mm
Bottom Bracket
SRAM GXP, outboard bearing
Chain
KMC X-10, 10-speed, hollow plates, hollow pins, nickel finish
Pedals
Resin Test Ride Pedals with toe clips, CEN std.
Wheels
Front Hub
Roval Traverse, w/ 20mm thru end caps, 27h
Rear Hub
Roval Traverse 142+, 12mm thru-axle, 32h
Rims
Roval Traverse, alloy disc, 28mm, 27/32h
Spokes
DT Swiss Super Comp, 2.0/1.65/1.8 stainless
Tires
Specialized Butcher Control, 60 TPI, 2Bliss Ready, aramid bead, dual-compound, 26x2.3""
Brakes
Brakes
Avid X0 World Cup, alloy backed semi-metal pad, Elixir lever w/carbon lever blade and reach adj.
Brake Levers
Custom Avid X0, carbon blade, tool-less reach adj. w/MatchMaker clamp
Cockpit
Stem
Syntace F109, 6º rise, 31.8mm clamp, S:60, M:60, L:75, XL 90mm
Handlebar
Specialized All-Mountain low-rise bar, uni-directional carbon, 720mm wide, 8º backsweep, 6º upsweep, 31.8mm
Grips
Specialized lock-on, S/M: Grappler, Others: Grappler XL
Headset
1-1/8 and 1-1/2"" Threadless, Campy style upper with 1-1/2"" lower, cartridge bearings
Seat
Saddle
Specialized Body Geometry Henge Expert, ti rails, 143mm width
Seatpost
Specialized Command Post BlackLite, 3 position, adjustable height w/air spring, remote operated, single bolt head 30.9mm, S:100mm travel, M/L/XL:125mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.36 mm | 1.32 mm | 1.3 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Stack | 580 mm | 590 mm | 608 mm | 626 mm |
| Reach | 407 mm | 434 mm | 460 mm | 480 mm |
| Top Tube Length | 563 mm | 593 mm | 623 mm | 648 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 420 mm | 444 mm | 467 mm | 520 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 120 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1123 mm | 1154 mm | 1188 mm | 1216 mm |
| Bottom Bracket Drop | -7 mm | -7 mm | -7 mm | -7 mm |
| Standover Height | 759 mm | 764 mm | 776 mm | 804 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
S-Works Enduro Carbon is part of the Specialized Enduro model. 117 bikes variations carry this model name so far. You can get a glimpse at all models from 2012, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro bikes
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
This bike has the Fox Float 36 fork installed. The fork’s travel is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
Specialized S-Works Enduro Carbon bike has the Fox RP23 Adaptive Logic model installed, and has a travel of 160mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the S-Works Enduro Carbon bike is equipped with the 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Specialized S-Works Enduro Carbon includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
