Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 95mm -
Travel Rear 95mm -
Fork RockShox SID
-
Groupset XX1 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 11m carbon front triangle, SWAT EMT tool cradle, 29"" World Cup geometry, FACT IS construction, full FACT carbon rear triangle, World Cup mega-chainstays, single ring only, tapered headtube, carbon PF30 BB, full internal shift/brake routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 95mm
Suspension Fork
Custom RockShox SID World Cup 29 Brain, inertia valve damper, Solo Air spring, tapered carbon crown/steerer, top-mount Brain Fade and rebound adj. 15mm thru-axle, 95mm travel
Rear Shock
FOX/Specialized remote Mini-Brain w/ AUTOSAG, Kashima coating, inertia valve w/ Aramid hose, Brain Fade adjust, 200x48mm, 95mm travel
Drivetrain
Rear Derailleur
SRAM XX1 Type 2, 11-speed
Shift Levers
SRAM XX1, 11-speed, carbon/aluminum trigger, w/ MatchMaker clamp
Cassette
SRAM XX1, 11-speed, 10-42
Crank
S-Works OS carbon, integrated 1-piece spider, custom SRAM XX1 style chainring, S: 170mm, Others: 175mm
Bottom Bracket
PF30, OS press-in bearings, sealed cartridge
Chain
SRAM XX1, 11-speed, hollow plates/pins, PowerLink
Wheels
Front Hub
Roval Control SL 29, alloy hub body w/ Labyrinth design, 15mm thru-axle, 24h
Rear Hub
Roval Control SL 29 142+, DT Swiss Star Ratchet, XX1 driver body, 12mm thru-axle, 28h
Rims
Roval Control SL 29, carbon disc, 22mm internal width, 24h/28h
Spokes
DT Swiss Revolution, 2.0/1.5/2.0mm stainless
Tires
S-Works Fast Trak, 2Bliss Ready, 29x2.0"", foldable aramid bead, 120 TPI
Brakes
Brakes
Magura MT8, hydraulic disc, Hi Friction pad, alloy caliper, Storm SL rotor, S/M: 160mm, L/XL: 180mm rotor
Brake Levers
Magura MT8, carbon master cylinder/lever blade, hollow lever pivot, reach adj.
Cockpit
Stem
Syntace F109, 6-degree rise, 31.8mm clamp
Handlebar
S-Works XC, flat bar, carbon, 700mm wide, 8-degree backsweep, 31.8mm
Grips
Specialized Sip Grip, light lock-on, half-waffle aramid-infused, S/M: regular, Others: XL thickness
Headset
1-1/8 and 1-1/2"" threadless, Campy style upper with 1-1/2"" lower, cartridge bearings
Seat
Saddle
Body Geometry Phenom Expert, hollow Ti rails, 143mm
Seatpost
Specialized carbon, single bolt, 27.2mm, S: 350mm, Others: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.465 mm | 1.411 mm | 1.37 mm | 1.355 mm |
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm | 332 mm |
| Front Center | 637 mm | 667 mm | 695 mm | 721 mm |
| Rake | 48 mm | 48 mm | 48 mm | 49 mm |
| Trail | 78 mm | 78 mm | 78 mm | 77 mm |
| Stack | 583 mm | 597 mm | 611 mm | 630 mm |
| Reach | 398 mm | 423 mm | 446 mm | 465 mm |
| Top Tube Length | 562 mm | 592 mm | 618 mm | 643 mm |
| Seat Tube Angle | 74.25 ° | 74.25 ° | 74.25 ° | 74.25 ° |
| Seat Tube Length | 400 mm | 434 mm | 470 mm | 520 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 90 mm | 105 mm | 120 mm | 140 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1073 mm | 1103 mm | 1131 mm | 1157 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 770 mm | 774 mm | 780 mm | 793 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
S-Works Epic 29 World Cup belongs to the Specialized Epic model. Specialized launched 161 bikes of this model so far. Check out the entire range from 2014 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The S-Works Epic 29 World Cup comes factory-installed with the RockShox SID fork. This has a travel range of 95mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Rear Shock
From the factory, it comes with the FOX/Specialized remote Mini-Brain w/ AUTOSAG rear shock model, which has a travel of 95mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
As for the wheels, Specialized S-Works Epic 29 World Cup 2014, has a 29″ carbon model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Specialized S-Works Epic 29 World Cup has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
S-Works Epic 29 World Cup comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
