Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 26" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox SID
-
Groupset XX, SRAM -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 11m carbon front triangle, FACT IS construction, gussetless TT (S/M), FACT carbon seatstays w/carbon non-drive DO and chainstays, tapered HT, carbon PF30 BB, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 100mm
Suspension Fork
Custom RockShox SID World Cup Brain, inertia valve damper, air spring, tapered carbon steerer, top-mount Brain Fade and rebound adj. QR, 100mm travel
Rear Shock
Fox/Specialized remote Mini-Brain w/new 2012 tune, Kashima coating, inertia valve, w/ Brain Fade adjust, 187x47mm
Drivetrain
Rear Derailleur
SRAM XX, 10-speed, mid cage
Front Derailleur
SRAM XX, S3 direct mount for DMD, top-swing, bottom-pull
Shift Levers
SRAM XX, 10-speed, carbon trigger, w/ MatchMaker clamp
Cassette
SRAM XX 10-speed, 11-36t
Crank
S-Works OS carbon crank, 10-speed XC double, custom SRAM spider/rings, S: 170mm, Others: 175mm
Bottom Bracket
S-Works OS, integrated for PF30
Chain
KMC X-10SL, 10-speed, hollow plates, hollow pins, nickel finish
Pedals
Resin Test Ride Pedals with toe clips, CEN std.
Wheels
Front Hub
Roval Control SL, carbon/alloy, OS 28mm end caps, QR, 24h
Rear Hub
Roval Control SL 142+, DT Star Ratchet, 12mm thru-axle, 28h
Rims
Roval Control SL, carbon disc, 25mm, 24/28h
Spokes
DT Swiss Revolution 2.0/1.5/2.0mm stainless, DT Aerolite, bladed, painted
Tires
S-Works Fast Trak, 120 TPI, 2Bliss ready aramid bead, dual-compound, 26x2.0""
Brakes
Brakes
Custom Avid XX World Cup R, alloy backed semi-metallic pad, reach adj. XX magnesium caliper, ti hardware package, 160mm rotor
Brake Levers
Custom Avid XX World Cup R hydraulic, tool-less reach adjust, magnesium body, carbon lever, w/MatchMaker clamp
Cockpit
Stem
Syntace F109, 6º rise, 31.8mm clamp, S: 75mm, M: 90mm, L: 100mm, XL: 110mm
Handlebar
S-Works XC Carbon flat bar, uni-directional carbon, 680mm wide, 8º back sweep, 31.8mm
Grips
Specialized lock-on, S/M: Grappler, Others: Grappler XL
Headset
1-1/8 and 1-1/2"" Threadless, Campy style upper with 1-1/2"" lower bearing for tapered integrated HT, cartridge bearings, carbon top cap
Seat
Saddle
Specialized Body Geometry Phenom Expert, ti rails, 143mm width
Seatpost
S-Works Carbon, single-bolt head, 30.9mm, 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.35 mm | 1.33 mm | 1.34 mm |
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm | 331 mm |
| Stack | 555 mm | 565 mm | 583 mm | 612 mm |
| Reach | 387 mm | 419 mm | 440 mm | 458 mm |
| Top Tube Length | 548 mm | 583 mm | 609 mm | 635 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 394 mm | 424 mm | 463 mm | 520 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 125 mm | 135 mm | 155 mm | 185 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1054 mm | 1090 mm | 1118 mm | 1146 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm | 12 mm |
| Standover Height | 749 mm | 759 mm | 768 mm | 784 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
S-Works Epic Carbon 26 belongs to the Specialized Epic model. There are 161 bikes that carry this model name. You can get a glimpse at all models from 2012, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The fork installed on this bike is the RockShox SID model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
S-Works Epic Carbon 26 has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Rear Shock
As for the rear shock, this bike has the Fox/Specialized remote Mini-Brain w/new 2012 tune model, with a travel of 100mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the S-Works Epic Carbon 26 bike is equipped with the 26″ carbon model. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Specialized S-Works Epic Carbon 26 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
