Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox SID
-
Groupset XX -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 11m carbon front triangle, 29"" geometry, FACT IS construction, gussetless TT (S/M), FACT carbon seatstays w/carbon non-drive DO and chainstays, tapered HT, carbon PF30 BB, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 100mm
Suspension Fork
Custom RockShox SID World Cup 29 Brain, inertia valve damper, air spring, tapered carbon steerer, top-mount Brain Fade adj and rebound adj. QR, 100mm travel
Rear Shock
Fox/Specialized remote Mini-Brain w/new 2012 tune, Kashima coating, inertia valve, w/ Brain Fade adjust, 187x47mm, 29er hose length
Drivetrain
Rear Derailleur
SRAM XX, 10-speed, mid cage
Front Derailleur
SRAM XX, S3 direct mount for DMD, top-swing, bottom-pull
Shift Levers
SRAM XX, 10-speed, carbon trigger, w/MatchMaker clamps
Cassette
SRAM XX 10-speed, 11-36t
Crank
S-Works OS carbon crank, 10-speed XC double, S: 170mm, Others: 175mm
Bottom Bracket
S-Works OS, integrated for PF30
Chain
KMC X-10SL, 10-speed, hollow plates, hollow pins, nickel finish
Pedals
Resin Test Ride Pedals with toe clips, CEN std.
Wheels
Front Hub
Roval Control SL 29, carbon/alloy, OS 28mm end caps, QR, 32h
Rear Hub
Roval Control SL 29 142+, DT Star Ratchet, 12mm thru-axle, 32h
Rims
Roval Control SL 29, carbon disc, 28mm, 32h
Spokes
DT Swiss Revolution 2.0/1.5/2.0mm stainless, DT Aerolite, bladed, painted
Tires
S-Works Fast Trak, 120 TPI, 2Bliss ready aramid bead, dual-compound, 29x2.0""
Brakes
Brakes
Custom Avid XX World Cup R, alloy backed semi-metallic pad, reach adj. XX magnesium caliper, ti hardware package, 160mm rotor
Brake Levers
Custom Avid XX World Cup R hydraulic, tool-less reach adjust, magnesium body, carbon lever, w/MatchMaker clamp
Cockpit
Stem
Syntace F109, 6º rise, 31.8mm clamp, S: 75mm, M: 90mm, L: 100mm, XL: 110mm
Handlebar
S-Works XC Carbon flat bar, uni-directional carbon, 680mm wide, 8º back sweep, 31.8mm
Grips
Specialized lock-on, S/M: Grappler, Others: Grappler XL
Headset
1-1/8 and 1-1/2"" Threadless, Campy style upper with 1-1/2"" lower, cartridge bearings, carbon top cap
Seat
Saddle
Specialized Body Geometry Phenom Expert, ti rails, 143mm width
Seatpost
S-Works Carbon, single-bolt head, 30.9mm, 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.46 mm | 1.41 mm | 1.39 mm |
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm | 331 mm |
| Stack | 580 mm | 599 mm | 608 mm | 627 mm |
| Reach | 380 mm | 409 mm | 432 mm | 452 mm |
| Top Tube Length | 548 mm | 583 mm | 609 mm | 635 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 394 mm | 424 mm | 463 mm | 520 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 90 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1069 mm | 1103 mm | 1130 mm | 1157 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm |
| Standover Height | 749 mm | 760 mm | 769 mm | 784 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
S-Works Epic Carbon 29 SRAM completes the Specialized Epic model. There are 161 bikes that carry this model name. Check out the entire range from 2012 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The fork installed on this bike is the RockShox SID model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Rear Shock
From the factory, it comes with the Fox/Specialized remote Mini-Brain w/new 2012 tune rear shock model, which has a travel of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
As for the wheels, Specialized S-Works Epic Carbon 29 SRAM 2012, has a 29″ carbon model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Specialized S-Works Epic Carbon 29 SRAM has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
S-Works Epic Carbon 29 SRAM comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
