Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 26" -
Travel Front 100mm -
Travel Rear 100mm -
Groupset XX, XTR -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Era FACT 10m carbon front triangle, w/ women's IS construction and geometry, FACT carbon seatstays and chainstays, sealed cartridge bearing pivots, 100mm travel, replaceable derailleur hanger
Suspension Fork
Specialized Future Shock e100, inertia valve, 100mm travel, Brain Fade, external rebound adj. single sided air spring and damper, carbon 1-1/8th to 1.5"" steerer
Rear Shock
Fox/SBC remote mini-brain, inertia valve, w/ Brain fade adjust
Drivetrain
Rear Derailleur
SRAM XX, 10-speed, standard cage
Front Derailleur
Shimano M971 XTR, DMD, top swing, dual pull
Shift Levers
SRAM XX carbon trigger
Cassette
SRAM XX, 10-speed, 11-36t
Crank
S-Works OS carbon crank, 10 speed compatible Scubic rings, S/M: 170mm, L: 175mm
Bottom Bracket
S-Works, OS, integrated
Chain
SRAM PC-1090, 10-speed
Pedals
None
Wheels
Front Hub
Roval Control SL Carbon, OS 28mm end caps
Rear Hub
Roval Control SL
Rims
Roval Control SL, disc, 24mm
Spokes
DT Aerolite
Tires
S-Works The Captain, 26x2.0"", 120 TPI, tubeless ready aramid bead, dual compound
Brakes
Brakes
Custom Avid XX R, alloy backed semi-metallic pads, magnesium caliper and lever body w/ carbon blade, ti hardware package, 160mm rotor
Brake Levers
Custom Avid XX Hydraulic, tool-less reach adjust, magnesium body, carbon lever
Cockpit
Stem
Syntace F109, 6 degree rise, 31.8mm clamp
Handlebar
Specialized S-Works XC Carbon low-rise bar, uni-directional carbon, 31.8mm, 640mm wide, 8 degree back sweep, 6 degree up
Grips
Specialized waffle lock on grip
Headset
1 1/8"" - 1 1/2"" Threadless, Campy style upper and lower cartridge bearing.
Seat
Saddle
Specialized Body Geometry women's Jett, ti rails, thin foam, 143mm
Seatpost
S-Works Carbon, 30.9mm, single-bolt head, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm |
| Stack | 542 mm | 560 mm | 569 mm |
| Reach | 380 mm | 399 mm | 427 mm |
| Top Tube Length | 534 mm | 559 mm | 589 mm |
| Seat Tube Angle | 74.2 ° | 74.2 ° | 74.2 ° |
| Seat Tube Length | 394 mm | 432 mm | 470 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 126 mm | 143 mm | 154 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1043 mm | 1070 mm | 1101 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm |
| Standover Height | 698 mm | 715 mm | 723 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
S-Works Era Carbon completes the Specialized Era model. Specialized released 20 bikes variations of this model so far. Take a sneak peek at all Specialized Era bikes models from 2010, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Rear Shock
The S-Works Era Carbon has a rear shock with a travel of 100mm. The model Fox/SBC remote mini-brain is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When it comes to wheels, the S-Works Era Carbon bike is equipped with the 26″ carbon model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The S-Works Era Carbon has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
