Bike details
Overview
Key information split into simple groups.
Frame summary
-
Category -
Frame Carbon -
Wheels 700c -
Travel Rear 100mm -
Suspension Full
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 10m carbon front triangle, women's FACT IS construction and geometry, tapered HT, OSBB, FACT carbon seatstays w/carbon drive DO and chainstays, sealed cartridge bearing pivots, replaceable derailleur hanger, 100mm travel
Suspension Fork
Specialized Future Shock E100, inertia valve damper custom tuned for women, 1 1/2-1 1/8"" carbon steer/crown, Brain Fade, external rebound adj. single sided air spring and damper, 100mm travel
Rear Shock
Fox/Specialized remote Mini-Brain, inertia valve, w/ Brain Fade adjust, 185x43mm
Cockpit
Headset
1-1/8 and 1.5"" Threadless, Campy style upper with 1.5"" lower, cartridge bearings
Seat
Seatpost
S-Works Carbon, single-bolt head, 30.9mm, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.35 mm | 1.33 mm | 1.34 mm |
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm | 331 mm |
| Stack | 555 mm | 565 mm | 583 mm | 612 mm |
| Reach | 387 mm | 419 mm | 440 mm | 458 mm |
| Top Tube Length | 548 mm | 583 mm | 609 mm | 635 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 394 mm | 424 mm | 463 mm | 520 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 125 mm | 135 mm | 155 mm | 185 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1054 mm | 1090 mm | 1118 mm | 1146 mm |
| Standover Height | 749 mm | 759 mm | 768 mm | 784 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
S-Works Era Carbon Frameset belongs to the Specialized Era model. Specialized launched 20 frames of this model so far. Take a sneak peek at all Specialized Era frames models from 2011, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry frames
According to our calculations, the average cost of a Crosscountry frame that is reliable is 1689$. However, even though the average price of a Crosscountry frame is lower, you might still be able to get a top-quality frame. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
Overview of components
Fork material
S-Works Era Carbon Frameset has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Rear Shock
The S-Works Era Carbon Frameset has a rear shock with a travel of 100mm. The model Fox/Specialized remote Mini-Brain is the one installed in this frame. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
