Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works FACT 11r carbon, FACT construction, Women's Endurance Geometry, women's layup, Zertz, carbon OSBB
Suspension Fork
S-Works FACT carbon w/ Zertz, full monocoque
Drivetrain
Rear Derailleur
Shimano Dura-Ace, 11-speed
Front Derailleur
Shimano Dura-Ace, 11-speed, braze-on
Shift Levers
Shimano Dura-Ace, 11-speed
Cassette
Shimano Dura-Ace, 11-speed, 11-28
Crank
S-Works FACT carbon, OSBB
Chain
Shimano Dura-Ace, 11-speed
Pedals
Nylon flat test ride, loose-ball, w/ reflectors
Wheels
Rims
Roval Rapide CLX 40, w/ CeramicSpeed ceramic bearings
Tires
S-Works Turbo, 220TPI, folding bead, BlackBelt protection, 700x26c
Brakes
Brakes
Shimano Dura-Ace
Cockpit
Stem
S-Works SL, alloy, 4-bolt
Handlebar
Specialized Women's SL Carbon, shallow drop, 125mm drop, 75mm reach
Headset
1-1/8"" upper, 1-3/8” lower, hybrid cartridge lightweight bearings, 8mm carbon cone spacer, w/ 20mm of carbon spacers
Seat
Saddle
Body Geometry Women's Ruby Pro, carbon rails, 155mm
Seatpost
Specialized CG-R, FACT carbon, single bolt, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 48cm | 51cm | 54cm | 57cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.44 mm | 1.48 mm | 1.52 mm | 1.52 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 263 mm | 264 mm |
| Front Center | 577 mm | 584 mm | 587 mm | 591 mm | 614 mm |
| Rake | 51 mm | 51 mm | 51 mm | 49 mm | 49 mm |
| Trail | 68 mm | 62 mm | 60 mm | 59 mm | 59 mm |
| Stack | 515 mm | 528 mm | 543 mm | 565 mm | 587 mm |
| Reach | 355 mm | 367 mm | 367 mm | 371 mm | 387 mm |
| Top Tube Length | 506 mm | 519 mm | 526 mm | 536 mm | 563 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 363 mm | 391.5 mm | 421.5 mm | 456.5 mm | 486.5 mm |
| Head Tube Angle | 70.25 ° | 71.25 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm | 165 mm | 190 mm |
| Chainstay Length | 409 mm | 412 mm | 412 mm | 412 mm | 414 mm |
| Wheelbase | 974 mm | 985 mm | 988 mm | 992 mm | 1018 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm | 71 mm |
| Standover Height | 699 mm | 718 mm | 737 mm | 765 mm | 789 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
S-Works Ruby belongs to the Specialized Ruby model. Specialized launched 78 bikes of this model so far. You can easily view all of the Specialized Ruby bikes models from 2015, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Endurance bikes average price
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
S-Works Ruby components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on S-Works Ruby are the 700c carbon type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Specialized S-Works Ruby has Rim brakes installed. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
