Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Groupset X0, XTR -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works Safire FSR FACT 10m carbon, Designs for Women specific main triangle, Az1 construction, M5 alloy chainstays with Brain mount, FACT 10m carbon seatstays with carbon drive side dropout, DMD Direct Mount F.Der, full cartridge bearing pivots, 120mm travel
Suspension Fork
Specialized Future Shock S120, 120mm travel, single sided air spring and damper, Trail Tune, Brain Fade, rebound adj. carbon 1-1/8"" to 1.5"" steerer, Safire tuned
Rear Shock
Specialized AFR Brain Shock w/ remote Trail Tune inertia valve, rebound adj. and Brain Fade, 7.25x1.75"", Safire tuned
Drivetrain
Rear Derailleur
SRAM X-0, 9-speed, mid cage
Front Derailleur
Shimano M971 XTR, DMD, top swing, dual pull
Shift Levers
SRAM X-0, carbon/aluminum trigger, 9-speed
Cassette
Shimano M970 XTR Ti, 9-speed, 11-34t
Crank
Shimano FC-M970 XTR, S/M: 170mm, L: 175mm
Bottom Bracket
Shimano M-970 XTR
Chain
Shimano XTR, 9-speed
Pedals
None
Wheels
Front Hub
Roval Controle SL XC Carbon, OS, 28mm axle caps, straight pull
Rear Hub
Roval Controle SL XC, OS, stragiht pull
Rims
Roval Controle SL, disc, 24mm
Spokes
DT Swiss Aerolite 2.0/1.6, black, alloy nipples
Tires
S-Works The Captain, 26x2.2"", 120 TPI, Aramid bead, dual compound, tubeless ready
Brakes
Brakes
Custom Avid Ultimate SL Mag, alloy backed organic pads, magnesium caliper and lever body w/ carbon blade, ti hardware package, 160mm rotor
Brake Levers
Custom Avid Ultimate SL Mag Hydraulic
Cockpit
Stem
Syntace F119 OS stem, 31.8, 6 degree rise
Handlebar
Specialized XC Carbon rise, OS 31.8 rise bar, 620mm wide, 6x8 degree w/SBC logo
Grips
Specialized thin lock on grip
Headset
1-1/8"" to 1.5"" Threadless, Campy style upper and lower cartridge bearing w/ adapter
Seat
Saddle
Specialized Women's Ariel SL, Ti rails, SL foam, 143mm
Seatpost
S-Works Carbon 30.9mm single-bolt head, S: 300mm: M/L 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm |
| Top Tube Length | 535 mm | 558 mm | 598 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 393 mm | 431 mm | 470 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 128 mm | 148 mm | 158 mm |
| Chainstay Length | 413 mm | 413 mm | 413 mm |
| Wheelbase | 1064 mm | 1089 mm | 1130 mm |
| Bottom Bracket Drop | 8 mm | 8 mm | 8 mm |
| Standover Height | 683 mm | 694 mm | 721 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
S-Works Safire FSR belongs to the Specialized Safire model. There are 14 bikes that carry this model name. Check out the entire range from 2009 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Rear Shock
From the factory, it comes with the Specialized AFR Brain Shock w/ remote Trail Tune inertia valve rear shock model, which has a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When it comes to wheels, the S-Works Safire FSR bike is equipped with the 26″ carbon model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The S-Works Safire FSR comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
