Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works FACT 11r carbon, FACT IS construction, crosswind-optimized airfoils, 1-1/8"" lower bearing, OSBB, Control Tower Fit System, Fuelselage Integrated Hydration System
Suspension Fork
Specialized FACT Aero carbon
Drivetrain
Crank
S-Works FACT carbon, w/ TT chainrings
Brakes
Brakes
Magura RT8TT
Brake Levers
Magura RT8TT
Cockpit
Stem
Shiv Aerostem
Handlebar
Specialized Carbon Aerobar
Headset
1-1/8"" upper/lower, hybrid cartridge bearings
Seat
Seatpost
Shiv Aero, FACT Carbon, +/-12.5mm and +/-37.5mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.34 mm | 1.33 mm | 1.33 mm | 1.32 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 573 mm | 589 mm | 608 mm | 631 mm | 659 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 61 mm | 63 mm | 60 mm | 60 mm |
| Stack | 498 mm | 518 mm | 543 mm | 568 mm | 593 mm |
| Reach | 368 mm | 388 mm | 408 mm | 428 mm | 448 mm |
| Top Tube Length | 484 mm | 507 mm | 533 mm | 560 mm | 585 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 505 mm | 525 mm | 551 mm | 577 mm | 603 mm |
| Head Tube Angle | 70.25 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 99 mm | 115 mm | 139 mm | 163 mm | 189 mm |
| Chainstay Length | 398 mm | 398 mm | 398 mm | 398 mm | 398 mm |
| Wheelbase | 960 mm | 976 mm | 995 mm | 1019 mm | 1046 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 755 mm | 775 mm | 800 mm | 825 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
S-Works Shiv Module is part of the Specialized Shiv model. 73 frames variations carry this model name so far. Check out the entire range from 2015 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Triathlon frames
According to our math, the average price for a trustworthy Triathlon frame is 3089$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Triathlon frame. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
When it comes to the fork, this frame has a carbon one, so, it’s a great addition to the frame’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Brakes
When you want to stop the bike in time, the brakes are vital. The S-Works Shiv Module has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
This frame is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
