Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 140mm -
Travel Rear 140mm -
Groupset XX, X0 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 10m carbon front triangle, FACT IS construction, tapered HT, OS BB, carbon seat stays, M5 aluminum chain stays, sealed cartridge bearing pivots, replaceable derailleur hanger, 140mm travel
Suspension Fork
Specialized Future Shock S140TA, Spike Valve damper, 1 1/2-1 1/8"" carbon steer/crown, comp and rebound adj. low bearing mount, 140-115mm travel adjust
Rear Shock
Specialized/Fox Brain Shock w/ remote Trail Tune inertia valve, Brain Fade and rebound adj. 7.75x1.9"", integrated cartridge bearing shock mount
Drivetrain
Rear Derailleur
SRAM XX, 10-speed, mid cage
Front Derailleur
SRAM X.0, 10-speed, S1 direct mount for DMD, bottom pull
Shift Levers
SRAM XX, 10-speed, carbon trigger, Match Maker clamp
Cassette
SRAM XX, 10-speed, 11-36t
Crank
S-Works OS carbon crank, 10-speed XC Trail double, custom XX spider/rings, S: 170mm, others: 175mm
Bottom Bracket
S-Works, OS, integrated
Chain
SRAM PC-1090, 10-speed
Pedals
Resin Test Ride Pedals with toe clips, CEN std.
Wheels
Front Hub
Roval Control Trail SL, carbon/alloy, 24h, OS 28mm end caps, QR
Rear Hub
Roval Control SL, DT Star Ratchet, 28h, QR
Rims
Roval Control Trail SL, alloy disc, 26mm, 24h
Spokes
DT Swiss Revolution 2.0/1.5/2.0mm stainless, DT Aerolite, bladed, painted
Tires
S-Works Purgatory, 120 TPI, 2Bliss ready aramid bead, dual compound, 26x2.2""
Brakes
Brakes
Custom Avid XX R, tool-less reach adj. alloy backed semi-metallic pads, magnesium caliper, ti hardware, S/M: 185mm, L/XL: 203mm rotor
Brake Levers
Custom Avid XX R hydraulic, tool-less reach adjust, magnesium body, carbon lever
Cockpit
Stem
Syntace F109, 6 degree rise, 31.8mm clamp
Handlebar
S-Works XC Carbon low-rise bar, uni-directional carbon, 680mm wide, 8 degree back sweep, 6 degree up, 31.8mm
Grips
Specialized lock-on, S/M: Grappler, Other: Rocca
Headset
1-1/8 and 1.5"" Threadless, Campy style upper with 1.5"" lower, cartridge bearings
Seat
Saddle
Specialized BG Henge Expert, Ti rails, 143mm width
Seatpost
S-Works Carbon, single-bolt head, 30.9mm, S/M: 350mm, other: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.37 mm | 1.31 mm | 1.27 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Stack | 571 mm | 590 mm | 600 mm | 609 mm |
| Reach | 404 mm | 430 mm | 458 mm | 480 mm |
| Top Tube Length | 562 mm | 593 mm | 623 mm | 648 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 406 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 118 mm | 138 mm | 148 mm | 158 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1089 mm | 1122 mm | 1153 mm | 1179 mm |
| Bottom Bracket Drop | 8 mm | 8 mm | 8 mm | 8 mm |
| Standover Height | 743 mm | 749 mm | 759 mm | 783 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
S-Works Stumpjumper FSR is part of the Specialized Stumpjumper model. Specialized launched 352 bikes of this model so far. You can easily view all of the Specialized Stumpjumper bikes models from 2011, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork material
S-Works Stumpjumper FSR has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Rear Shock
Specialized S-Works Stumpjumper FSR bike has the Specialized/Fox Brain Shock w/ remote Trail Tune inertia valve model installed, and has a travel of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The wheels on S-Works Stumpjumper FSR are the 26″ aluminum type. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The S-Works Stumpjumper FSR has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
