Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 10 Electronic -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works Tarmac SL3 FACT 11r, FACT IS construction, compact race design, 1.5"" lower HS bearing, OS carbon BB shell
Suspension Fork
S-Works Tarmac SL3 FACT carbon, Uni-weave, monocoque construction, OS race for 1.5"" bearing, full carbon legs, crown and steerer
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2
Front Derailleur
Shimano Dura-Ace Di2
Shift Levers
Shimano Dura-Ace Di2
Cassette
Shimano Dura Ace, 10-speed, 12-27t
Crank
S-Works Crankset 53x39
Bottom Bracket
Ceramic bearings
Chain
Shimano Dura-Ace
Pedals
Silver cage/black body, w/ black toe clips and strap
Wheels
Rims
Roval Rapide SL 45
Tires
S-Works Mondo Open Tubular, 700x23c, 290TPI
Brakes
Brakes
Shimano Dura-Ace
Brake Levers
Shimano Dura-Ace Di2
Cockpit
Stem
S-Works 3D forged with carbon-wrap top and front cap
Handlebar
S-Works SL Carbon, classic bend
Headset
Aheadset Stainless Race Steel Balls w/ top cap w/ 20mm of spacers
Seat
Saddle
Body Geometry Toupe Carbon 143 w/ Hollow Ti rails
Seatpost
S-Works FACT carbon w/ Zertz insert, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 264 mm | 264 mm | 267 mm | 267 mm | 268 mm | 268 mm |
| Front Center | 576 mm | 576 mm | 583 mm | 591 mm | 605 mm | 613 mm |
| Rake | 45 mm | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 62 mm | 57 mm | 57 mm | 56 mm | 56 mm | 53 mm |
| Top Tube Length | 510 mm | 529 mm | 540 mm | 557 mm | 574 mm | 592 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 510 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 72.25 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 100 mm | 120 mm | 145 mm | 170 mm | 205 mm | 230 mm |
| Chainstay Length | 397 mm | 397 mm | 397 mm | 397 mm | 399 mm | 402 mm |
| Wheelbase | 933 mm | 953 mm | 965 mm | 980 mm | 1000 mm | 1022 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 722 mm | 747 mm | 769 mm | 792 mm | 820 mm | 849 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
Model Overview
S-Works Tarmac SL3 Di2 is part of the Specialized Tarmac model. There are 279 bikes that carry this model name. Take a sneak peek at all Specialized Tarmac bikes models from 2010, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
S-Works Tarmac SL3 Di2 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the S-Works Tarmac SL3 Di2 bike is equipped with the 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
S-Works Tarmac SL3 Di2 comes in 6 sizes, that range from 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, you can easily find one that suits you.
