Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED, SRAM -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized FACT 9r N'Aero tube shaping, triple monocoque construction, compact aero geometry, vertical seat adjustment, OS BB
Suspension Fork
Specialized FACT N'Aero carbon, monocoque construction, 1"" steerer
Drivetrain
Rear Derailleur
SRAM Red
Front Derailleur
SRAM Red, braze-on clamp
Shift Levers
SRAM TT, 10-speed bar end shifters
Cassette
SRAM OG 1090, 10-speed 11-25t
Crank
S-Works FACT carbon, integrated oversize design
Bottom Bracket
S-Works oversize integrated
Chain
SRAM 1090R, 10-speed
Pedals
Silver cage, black body, w/ toe clip and strap
Wheels
Front Hub
Zipp 404
Rear Hub
Zipp 404
Rims
Zipp 404 carbon clincher
Spokes
Stainless
Tires
S-Works Mondo, 700x21c, dual-compound tread, aramid bead, 290TPI
Brakes
Brakes
S-Works integrated brake system
Brake Levers
SRAM aero levers
Cockpit
Stem
S-Works Pro-Set, 3D forged, carbon/alloy face plate w/ Ti bolts, carbon top cap, 4-position adjustable
Handlebar
Easton Attack TT aero bar
Headset
S-Works 1"" integrated threadless, sealed cartridge ceramic bearings w/ stainless steel races, conical cover w/ two 10mm and two 5mm carbon spacers
Seat
Saddle
Body Geometry TriTip, super light foam, carbon reinforced base, hollow Ti rails, microfiber cover, 50mm nose width
Seatpost
S-Works Transition carbon, forward and setback posts, 2 position
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 352 mm | 352 mm | 372 mm | 371 mm |
| Head Tube Length | 170 mm | 172.5 mm | 175 mm | 175 mm |
| Wheelbase | 400 mm | 400 mm | 420 mm | 420 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
S-Works Transition completes the Specialized Transition model. 21 bikes variations carry this model name so far. Take a sneak peek at all Specialized Transition bikes models from 2009, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Triathlon bikes average price
According to our math, the average price for a trustworthy Triathlon bike is 4177$. However, this doesn’t mean that if you spend less money on a Triathlon bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
S-Works Transition components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on S-Works Transition are the 700c carbon type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
