Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED, SRAM -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 173cm
MD
169cm - 180cm
LG
177cm - 186cm
XL
183cm - 191cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works Transition FACT 9r N'Aero tube shaping, triple monocoque construction, compact aero geometry, vertical seat adjustment, OS BB
Suspension Fork
Transition FACT N'Aero carbon, monocoque construction, 1"" steerer
Drivetrain
Rear Derailleur
SRAM RED
Front Derailleur
SRAM RED
Shift Levers
SRAM SL Aero TT lever
Cassette
SRAM RED, 10-speed, 11-25t
Crank
S-Works Crankset 53x39
Bottom Bracket
Ceramic bearings
Chain
KMC X10 Superlight
Pedals
Silver cage/black body, w/ black toe clips and strap
Wheels
Rims
Zipp 404 Clincher
Tires
S-Works Mondo Open Tubular, 700x21c, 290TPI
Brakes
Brakes
S-Works Aero Brake
Brake Levers
SRAM TT lever
Cockpit
Stem
S-Works 3D forged with carbon-wrap top and front cap
Handlebar
Profile carbon X3
Headset
1"" Ahead set, 30mm carbon spacers (2x10mm, 2x5mm), no top cap
Seat
Saddle
Body Geometry TriTip 50 w/ hollow Ti rails
Seatpost
S-Works Transition Aero Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.33 mm | 1.31 mm | 1.3 mm | 1.29 mm | 1.23 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 577 mm | 575 mm | 589 mm | 602 mm | 621 mm | 652 mm |
| Rake | 49 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 74 mm | 68 mm | 65 mm | 65 mm | 61 mm | 61 mm |
| Stack | 481 mm | 499 mm | 510 mm | 520 mm | 536 mm | 548 mm |
| Reach | 359 mm | 374 mm | 389 mm | 399 mm | 415 mm | 444 mm |
| Seat Tube Length | 445 mm | 445 mm | 445 mm | 445 mm | 475 mm | 495 mm |
| Head Tube Angle | 69.5 ° | 71.5 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm | 135 mm | 150 mm |
| Chainstay Length | 389 mm | 389 mm | 389 mm | 389 mm | 389 mm | 389 mm |
| Wheelbase | 955 mm | 955 mm | 969 mm | 982 mm | 1001 mm | 1030 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 713 mm | 755 mm | 757 mm | 762 mm | 787 mm | 801 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 165 cm | 169 cm | 177 cm | 183 cm | 186 cm |
| Rider Max Height | 167 cm | 173 cm | 180 cm | 186 cm | 191 cm | 194 cm |
About this model
S-Works Transition completes the Specialized Transition model. 21 bikes variations carry this model name so far. Take a sneak peek at all Specialized Transition bikes models from 2010, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Triathlon bikes average price
Our math shows that the average cost of a dependable Triathlon bike is 4177$. However, even if your budget is less than the average, you might still be able to get a top-quality Triathlon bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
S-Works Transition has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Specialized S-Works Transition 2010, has a 700c carbon model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized S-Works Transition is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 6 sizes. They vary from 158 cm – 194 cm (5.18 ft – 6.36 ft). In conclusion, you won’t have a problem finding one that suits you.
