Specialized S-Works Turbo Levo SL 2020
2020 E-bike
Estimate price |
13,525$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Factory Float 34
-
Groupset XX1 Eagle, SRAM -
Suspension Full -
Motor Specialized 240W 35Nm mid-drive -
Battery Specialized SL1-320, fully integrated, 320Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 11m full carbon, 29 Trail Geometry, Integrated down tube battery, enclosed internal cable, Command Post routing, 148mm spacing, fully sealed cartridge bearings, 150mm of travel
Suspension Fork
FOX Factory 34 FLOAT 29, Kashima Coating, FIT4 damper, 51mm offset, 3-position adjustment, 15x110mm, tapered alloy steerer, 150mm of travel
Rear Shock
FOX FLOAT DPS Factory, Kashima coating, 3-position adjustment, 52.5x210mm, Rx Trail Tune
Drivetrain
Rear Derailleur
SRAM XX1 Eagle, 12-speed
Shift Levers
SRAM XX1 Eagle, trigger, 12-speed
Cassette
SRAM XG-1299 Eagle, 10-50t
Crank
Praxis, carbon M30, custom offset, SRAM X-Sync Eagle, 94 BCD, 30T
Chain
SRAM XX1 Eagle, 12-speed
Wheels
Front Hub
Roval Traverse SL, sealed cartridge bearings, 15mm thru-axle, 110mm spacing
Rear Hub
Roval Traverse SL, DT Swiss Star Ratchet, 54t engagement, SRAM XD driver body, 12mm thru-axle, 148mm spacing
Rims
Front: Traverse SL 29, Rear: Traverse SL 29
Spokes
DT Competition Race
Tires
Front: Butcher, GRID TRAIL casing, GRIPTON® compound, 29x2.3", Rear: Eliminator, GRID TRAIL casing, GRIPTON® compound, 2Bliss Ready, 29x2.3"
Brakes
Brakes
SRAM G2 ULTIMATE, 4-piston caliper, hydraulic disc, 200mm
Cockpit
Stem
Syntace MegaForce 2, 6-degree, 31.8mm clamp
Handlebar
Specialized Trail, FACT Carbon, 6-degree upsweep, 8-degree backsweep, 27mm rise, 780mm, 31.8mm
Seat
Saddle
Bridge, 155/143mm, Hollow Ti-rails
Seatpost
RockShox Reverb AXS, 30.9mm, S: 125, M:150, L/XL: 170mm
Motor & Battery
Motor
Specialized SL 1.1, custom lightweight motor
Battery
Specialized SL1-320, fully integrated, 320Wh
Charger
Custom charger, 48V System w/ SL system charger plug
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.39 mm | 1.34 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 729 mm | 749 mm | 781 mm | 812 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 613 mm | 613 mm | 640 mm | 654 mm |
| Reach | 422 mm | 442 mm | 462 mm | 487 mm |
| Top Tube Length | 581 mm | 604 mm | 636 mm | 670 mm |
| Seat Tube Angle | 75.3 ° | 75 ° | 74.6 ° | 74.2 ° |
| Seat Tube Length | 390 mm | 410 mm | 455 mm | 505 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 95 mm | 95 mm | 125 mm | 140 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1172 mm | 1192 mm | 1224 mm | 1255 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 794 mm | 797 mm | 814 mm | 821 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
S-Works Turbo Levo SL completes the Specialized E Turbo Levo model. Specialized released 86 e-bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
The most economical model, the Specialized Turbo Levo Hardtail 2020 has a starting price of 3041$. Specialized S-Works Turbo Levo SL 2020 on the other hand is the most expensive at 13525$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Enduro e-bikes average price
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2020 for 13525$. In conclusion, this e-bike price is 182.65% higher than the price of the average Enduro e-bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The Fox Factory Float 34 is included from the factory. It has a travel distance of 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the e-bike. However, they are not so stiff as carbon forks are.
Rear Shock
Specialized S-Works Turbo Levo SL e-bike has the FOX FLOAT DPS Factory model installed, and has a travel of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When it comes to wheels, the S-Works Turbo Levo SL e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized S-Works Turbo Levo SL is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
