Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-Works FACT 11r carbon, Rider-First Engineered™, Win Tunnel Engineered, internal electric only cable routing, OSBB, 12x142mm thru-axle, flat-mount disc
Suspension Fork
S-Works FACT 11r carbon, 100x12mm thru-axle, flat-mount disc
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2 R9150, 11-speed
Front Derailleur
Shimano Dura-Ace Di2 R9150, braze-on
Shift Levers
Shimano Dura-Ace Di2 Disc R9170
Cassette
Shimano Dura-Ace 9100, 11-speed, 11-28t
Crank
S-Works Power Cranks, dual-sided power measurement, +/- 1.5% accuracy, 52/36T
Bottom Bracket
OSBB, CeramicSpeed bearings
Chain
Shimano Dura-Ace, 11-speed
Pedals
Nylon, 105x78x28mm, loose ball w/reflectors
Wheels
Rims
Roval CLX 64 Disc, carbon, tubeless-ready, Win Tunnel Engineered, 64mm depth, DT Swiss 240 internals, CeramicSpeed bearings, 24h
Tires
Turbo Cotton, 320 TPI, 700x26mm
Brakes
Brakes
Shimano Dura-Ace R9170, hydraulic disc
Cockpit
Stem
Venge integrated stem, 6-degree
Handlebar
S-Works Aerofly II, 80mm reach x 130mm drop
Seat
Saddle
S-Works Power, 143mm, carbon rails, carbon base, synthetic leather
Seatpost
2019 S-Works Venge aero seatpost, FACT carbon, Di2-compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.35 mm | 1.38 mm | 1.39 mm | 1.43 mm | 1.46 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 574 mm | 577 mm | 579 mm | 591 mm | 606 mm | 613 mm |
| Rake | 47 mm | 47 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 63 mm | 58 mm | 58 mm | 55 mm | 55 mm | 52 mm |
| Stack | 508 mm | 521 mm | 538 mm | 559 mm | 585 mm | 606 mm |
| Reach | 382 mm | 387 mm | 391 mm | 402 mm | 409 mm | 415 mm |
| Top Tube Length | 512 mm | 535 mm | 544 mm | 566 mm | 581 mm | 599 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 455 mm | 480 mm | 495 mm | 518 mm | 537 mm | 567 mm |
| Head Tube Angle | 71.75 ° | 72.5 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 104 mm | 115 mm | 133 mm | 153 mm | 180 mm | 200 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 976 mm | 979 mm | 982 mm | 995 mm | 1009 mm | 1016 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 740 mm | 760 mm | 777 mm | 799 mm | 821 mm | 845 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
S-Works Venge belongs to the Specialized Venge model. There are 62 bikes that carry this model name. Take a sneak peek at all Specialized Venge bikes models from 2019, by clicking here.
Model range prices
Specialized Venge Pro 2019 is the most economical model, with a starting price of 8020$. Specialized S-Works Venge – Sagan Collection 2019 on the other hand costs 13250$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Aero bikes
Our math shows that the average cost of a dependable Aero bike is 4211$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Aero bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Specialized S-Works Venge price was 12520$. Doing a quick comparison, we notice that S-Works Venge price is 197.32% higher than the average cost of an Aero bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the S-Works Venge bike is equipped with the 700c carbon model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized S-Works Venge is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
S-Works Venge comes in 6 sizes, that range from 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, you can easily find one that suits you.
