Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox
-
Groupset X9, SLX -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Safire FSR M5 Manipulated Alloy frame w/ Designs for Women specific ORE TT/DT, sealed cartridge bearing pivots, DMD Direct Mount F. Der, replaceable derailleur hanger, disc only, 120mm travel
Suspension Fork
Fox Float 120 RL, 120mm travel, compression and rebound adjust w/ LO, alloy steerer
Rear Shock
Fox Triad, custom on-the-fly 3-position switch 1) lock out 2) Open 3) ProPedal pedal assisting damping, rebound adj. 7.25x1.75""
Drivetrain
Rear Derailleur
SRAM X-9, 9-speed, mid cage
Front Derailleur
Shimano M660 SLX, DMD, top swing, dual pull
Shift Levers
SRAM X-7, aluminum trigger, 9-speed
Cassette
Shimano HG61, 9-speed, 11-34t
Crank
Custom Shimano FC-M542, S/M: 170mm, L: 175mm
Bottom Bracket
Custom Shimano FC-M542
Chain
SRAM PC-971, 9-speed w/Power Link
Pedals
Shimano M520, clipless
Wheels
Front Hub
Specialized Hi Lo disc, CNC flange, sealed cartridge bearing, 9mm DT RWS, alloy QR, 28h
Rear Hub
Custom Shimano M525 SL, alloy QR, 32h
Rims
Custom DT Swiss X420SL, 24mm w/ eyelets, 28/32h
Spokes
DT Swiss 1.8mm stainless, black, alloy nipples
Tires
S-Works The Captain, 26x2.2"", 120 TPI, Aramid bead, dual compound, tubeless ready
Brakes
Brakes
Custom Avid Elixir R SL, alloy backed organic pads, 160 mm rotor
Brake Levers
Custom Avid Elixir R SL Hydraulic, tool-less adj. reach
Cockpit
Stem
Specialized adjustable rise, 31.8mm clamp, 3D forged w/ CNC finish
Handlebar
Specialized XC low rise 31.8mm bar, 6066 butted alloy, 6 degree up, 8 degree backsweep, 620mm wide
Grips
Specialized thin lock on grip
Headset
1-1/8"" Threadless, 10mm insertion alloy cups, sealed cartridge bearing
Seat
Saddle
Specialized Women's Ariel, hollow Cr-Mo rails, 143mm
Seatpost
2014 butted alloy, single-bolt setback, 30.9x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm |
| Top Tube Length | 536 mm | 559 mm | 599 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 394 mm | 431 mm | 470 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 120 mm | 130 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm |
| Wheelbase | 1062 mm | 1087 mm | 1128 mm |
| Bottom Bracket Drop | 8 mm | 8 mm | 8 mm |
| Standover Height | 684 mm | 690 mm | 711 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Safire FSR Comp is part of the Specialized Safire model. Specialized released 14 bikes variations of this model so far. You can get a glimpse at all models from 2009, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Safire FSR Comp components
Fork
The Safire FSR Comp comes factory-installed with the Fox fork. This has a travel range of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
Safire FSR Comp has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
The Safire FSR Comp has a rear shock with a travel of 120mm. The model Fox Triad is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on Safire FSR Comp are the 26″ aluminum type. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized Safire FSR Comp is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Specialized Safire FSR Comp bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
