Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized A1 Premium Aluminum disc, fully-manipulated tubing w/ smooth welds, Compliance Plus seatstays, 1-1/8"" lower bearing
Suspension Fork
Specialized disc FACT carbon monocoque w/ Zertz inserts, alloy steerer/crown, fender fittings
Drivetrain
Rear Derailleur
Shimano Tiagra, 10-speed
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra STI
Cassette
Shimano Tiagra, 10-speed, 12-30
Crank
FSA Tempo, 10-speed compact
Bottom Bracket
FSA, square taper, sealed cartridge bearings
Chain
KMC X10
Pedals
Nylon flat test ride, loose ball, w/ reflectors
Wheels
Rims
AXIS Classic Disc
Tires
Specialized Espoir Sport, 60TPI, wire bead, double BlackBelt protection, 700x30c
Brakes
Brakes
Avid BB5, mechanical disc, 160mm rotor
Cockpit
Stem
Specialized Elite-Set, 3D forged alloy, 4-position adjustable, 4-bolt, 31.8mm clamp
Handlebar
Specialized Comp, shallow bend
Headset
1-1/8"" sealed Cr-Mo cartridge bearings integrated w/ headset, 20mm alloy cone spacer, w/ 20mm of spacers
Seat
Saddle
Body Geometry Riva Plus, Cr-Mo rails, 143mm
Seatpost
Specialized Sport, alloy, 2-bolt, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.45 mm | 1.48 mm | 1.52 mm | 1.59 mm | 1.61 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 264 mm | 264 mm | 266 mm | 266 mm |
| Front Center | 582 mm | 588 mm | 595 mm | 606 mm | 621 mm | 628 mm |
| Rake | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 59 mm | 59 mm | 59 mm | 56 mm | 56 mm | 53 mm |
| Stack | 529 mm | 548 mm | 565 mm | 591 mm | 623 mm | 644 mm |
| Reach | 379 mm | 379 mm | 381 mm | 388 mm | 392 mm | 399 mm |
| Top Tube Length | 519 mm | 538 mm | 549 mm | 566 mm | 583 mm | 601 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 418 mm | 447 mm | 466 mm | 485 mm | 510 mm | 535 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° | 73 ° |
| Head Tube Length | 94 mm | 114 mm | 134 mm | 159 mm | 194 mm | 214 mm |
| Chainstay Length | 413 mm | 413 mm | 416 mm | 416 mm | 419 mm | 421 mm |
| Wheelbase | 984 mm | 990 mm | 1001 mm | 1011 mm | 1030 mm | 1039 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 71 mm | 71 mm | 70 mm | 70 mm |
| Standover Height | 731 mm | 757 mm | 777 mm | 799 mm | 830 mm | 852 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Secteur Elite Disc is part of the Specialized Secteur model. Specialized released 30 bikes variations of this model so far. Take a sneak peek at all Specialized Secteur bikes models from 2014, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Endurance bikes average price
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
Secteur Elite Disc has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When it comes to wheels, the Secteur Elite Disc bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Secteur Elite Disc has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Specialized Secteur Elite Disc bike has 6 sizes, in the range of 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, you won’t have a problem finding one that suits you.
