Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Specialized Shiv Pro 10r carbon, FACT IS construction, crosswind-optimized airfoils, 1-1/8"" lower bearing, OSBB, Control Tower Fit System, Fuelselage Integrated Hydration System
Suspension Fork
Specialized FACT Aero carbon monocoque fork, carbon steerer and crown for 1-1/8"" bearing
Drivetrain
Bottom Bracket
OS integrated, sealed bearings
Brakes
Brakes
Specialized Shiv Aero
Cockpit
Headset
1-1/8"" upper and lower, stainless steel cartridge bearings
Seat
Seatpost
Shiv Aero FACT carbon, 12.5mm and 37.5mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.34 mm | 1.33 mm | 1.33 mm | 1.32 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 573 mm | 589 mm | 608 mm | 631 mm | 659 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 61 mm | 63 mm | 60 mm | 60 mm |
| Stack | 498 mm | 518 mm | 543 mm | 568 mm | 593 mm |
| Reach | 368 mm | 388 mm | 408 mm | 428 mm | 448 mm |
| Top Tube Length | 484 mm | 507 mm | 533 mm | 560 mm | 585 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 505 mm | 525 mm | 551 mm | 577 mm | 603 mm |
| Head Tube Angle | 70.25 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 99 mm | 115 mm | 139 mm | 163 mm | 189 mm |
| Chainstay Length | 398 mm | 398 mm | 398 mm | 398 mm | 398 mm |
| Wheelbase | 960 mm | 976 mm | 995 mm | 1019 mm | 1046 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 755 mm | 775 mm | 800 mm | 825 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Shiv Pro OSBB Frameset belongs to the Specialized Shiv model. Specialized released 73 frames variations of this model so far. You can get a glimpse at all models from 2013, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Triathlon frames average price
If you want an acceptable Triathlon frame you should know that the average price is 3089$. However, even though the average price of a Triathlon frame is lower, you might still be able to get a top-quality frame. In conclusion, always check frame reviews and their components before making a purchase to make sure you don’t overpay.
Shiv Pro OSBB Frameset components
Fork material
The fork on this frame is made out of carbon, so, it’s a great addition to the frame’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Brakes
Stopping the bike when needed, it’s essential for your safety. This frame has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Shiv Pro OSBB Frameset comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
