Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 160mm -
Fork Fox Rhythm Float 36
-
Groupset NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
S1
149cm - 160cm
S2
157cm - 172cm
S3
165cm - 180cm
S4
172cm - 188cm
S5
177cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M5 alloy chassis and rear-end, Mixed wheel Trail Geometry, threaded BB,12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 160mm of travel
Suspension Fork
FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, 160mm of travel
Rear Shock
FOX FLOAT DPX2 Performance, Rx Trail Tune, EVOL Air sleeve, 3-position adjustment, 230x60mm
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12-speed
Shift Levers
SRAM NX Eagle, trigger, 12-speed
Cassette
SRAM NX Eagle PG-1230, 12-speed, 11-50t
Crank
SRAM NX Eagle, DUB, 170mm
Bottom Bracket
SRAM DUB, BSA 73mm, threaded
Chain
SRAM NX Eagle, 12-speed
Wheels
Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
Rims
Specialized 29, hookless alloy, 30mm inner width, tubeless ready
Spokes
DT Swiss Industry
Tires
Front: Butcher, GRID TRAIL casing, GRIPTON® compound, 29x2.3", Rear: Butcher, GRID TRAIL casing, GRIPTON® compound, 27.5x2.3"
Brakes
Brakes
Front: SRAM Code R, 4-piston caliper, hydraulic disc, 220mm, Rear: SRAM Code R, 4-piston caliper, hydraulic disc, 220mm
Cockpit
Stem
Alloy Trail Stem, 35mm bar bore
Handlebar
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
Grips
Deity, Knuckleduster, Black
Seat
Saddle
Body Geometry Bridge Comp, hollow Cr-Mo rails, 143mm
Seatpost
SEAT POST, A-PRO, MANIC, 22-XPMCMLG-125/150/170-011,FORGED,6066-T6 ,2-BOLT,34.9, 125/150/170 TRAVEL, OFFSET 0MM,361.5/425.5/470.5MM,SCM435,ZINC FINISH BOLT
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | S1 | S2 | S3 | S4 | S5 |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.463 mm | 1.405 mm | 1.348 mm | 1.298 mm | 1.252 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm | 338 mm |
| Front Center | 756 mm | 778 mm | 808 mm | 837 mm | 867 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 141 mm | 141 mm | 141 mm | 141 mm | 141 mm |
| Stack | 610 mm | 614 mm | 623 mm | 632 mm | 641 mm |
| Reach | 417 mm | 437 mm | 462 mm | 487 mm | 512 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 400 mm | 420 mm | 440 mm | 465 mm |
| Head Tube Angle | 63.2 ° | 63.2 ° | 63.2 ° | 63.2 ° | 63.2 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1181 mm | 1203 mm | 1233 mm | 1264 mm | 1292 mm |
| Bottom Bracket Drop | 17 mm | 17 mm | 17 mm | 17 mm | 17 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 149 cm | 157 cm | 165 cm | 172 cm | 177 cm |
| Rider Max Height | 160 cm | 172 cm | 180 cm | 188 cm | 193 cm |
About this model
Status 160 is part of the Specialized Status model. Specialized launched 19 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the Specialized Status 140 2023 has a starting price of 3000$. Specialized Status 160 2023 on the other hand is the most expensive at 3000$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Specialized released this model in 2023, its price was 3000$. Comparing this to the average Enduro bike price, we see that the price is 19.97% smaller.
Overview of components
Fork
The Status 160 comes factory-installed with the Fox Rhythm Float 36 fork. This has a travel range of 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Specialized Status 160 bike has the FOX FLOAT DPX2 Performance model installed, and has a travel of 160mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Specialized Status 160 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Status 160 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 5 sizes. They vary from 149 cm – 193 cm (4.89 ft – 6.33 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the Status 160. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
