Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 200mm -
Travel Rear 200mm -
Fork RockShox Domain
-
Groupset X7, X5 -
Suspension Full -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M4 hydroformed tubing, 1.5"" forged HT, ISCG mounts, 135mm rear spacing, full cartridge bearing pivots, 200mm travel
Suspension Fork
RockShox Domain Dual Crown R, coil spring, alloy steerer, rebound adj. 20mm Maxle DH thru-axle, 200mm travel
Rear Shock
Fox Van RC, coil w/piggy back, compression and rebound adj. 8.75x2.75"", S:450, M:500, L:550
Drivetrain
Rear Derailleur
SRAM X7, 9-speed, short cage
Shift Levers
SRAM X5, 9-speed, trigger
Cassette
SRAM PG-950, 9-speed, 11-28t
Crank
FSA Gravity Moto-X MegaExo, forged solid arms, 165mm, w/Status guide
Bottom Bracket
FSA MegaExo, sealed outboard cartridge bearing for Moto-X crank, 73mm shell
Chain
SRAM 9-speed w/ PowerLink
Pedals
Alloy platform, 9/16""
Wheels
Front Hub
Specialized Hi Lo disc, laser-etched logo, sealed cartridge bearing, 20mm thru-axle, 36h
Rear Hub
Specialized Hi Lo disc, laser-etched logo, sealed cartridge bearing, 10mm bolt-on, 36h
Rims
P-Disc, 32mm, 36h
Spokes
Stainless, 2.0mm (14g)
Tires
Specialized Butcher DH, DH casing, wire bead, soft dual-compound, 26x2.3""
Brakes
Brakes
Avid Elixir 5, hydraulic disc, metallic pad, HS-1 rotor, 200mm rotor
Brake Levers
Avid Elixir 5 hydraulic
Cockpit
Stem
Specialized Direct-Mount stem, 40mm length, 31.8mm, 4-bolt, forged
Handlebar
Specialized Demo low-rise bar, 6061 alloy, 750mm wide, 9º backsweep, 6º upsweep, 31.8mm
Grips
Specialized lock-on, S/M: Grappler, Others: Grappler XL
Headset
Semi-integrated alloy cups for 1.5"" HT and 1-1/8"" steerer, cartridge bearings
Seat
Saddle
Specialized DH, 8mm steel rails
Seatpost
6061 alloy, two bolt micro adjust, no offset, 30.9mm, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.53 mm | 1.44 mm |
| Bottom Bracket Height | 355 mm | 355 mm | 355 mm |
| Front Center | 739 mm | 764 mm | 789 mm |
| Rake | 3 mm | 21 mm | 21 mm |
| Trail | 160 mm | 140 mm | 140 mm |
| Stack | 640 mm | 640 mm | 640 mm |
| Reach | 414 mm | 419 mm | 444 mm |
| Top Tube Length | 552 mm | 577 mm | 602 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 394 mm | 419 mm | 458 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1158 mm | 1183 mm | 1208 mm |
| Bottom Bracket Drop | -14 mm | -14 mm | -14 mm |
| Standover Height | 740 mm | 737 mm | 753 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Status II is part of the Specialized Status model. There are 19 bikes that carry this model name. Check out the entire range from 2012 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Downhill bikes
If you want an acceptable Downhill bike you should know that the average price is 3391$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Downhill bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The Status II comes factory-installed with the RockShox Domain fork. This has a travel range of 200mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
The shock that’s installed on this bike is Fox Van RC, with a travel distance of 200mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The wheels on Status II are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized Status II is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Status II comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
