Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 90mm -
Fork RockShox Reba
-
Groupset X9, X7 -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M5 fully manipulated alloy, 29"" geometry, tapered headtube, PF30 BB, PM 140mm rear brake, 135mm dropouts, replaceable derailleur hanger
Suspension Fork
RockShox Reba RL 29, Solo Air spring, alloy tapered steerer, lockout and reb adj. 15mm thru-axle, 15.5"": 80mm Others: 90mm travel
Drivetrain
Rear Derailleur
SRAM X9 Type 2, 10-speed, mid cage
Front Derailleur
SRAM X7, 10-speed, 34.9mm clamp, top pull
Shift Levers
SRAM X7, 10-speed, w/ Shiftmix clamp
Cassette
SRAM PG-1030, 10-speed, 11-36
Crank
Custom SRAM S-1250, 7050 alloy arms, 10-speed XC double, PF30 spindle, S: 170mm, Others: 175mm
Bottom Bracket
SRAM PF30, OS press-in bearings, sealed cartridge
Chain
SRAM PC 1031, 10-speed, PowerLink
Wheels
Front Hub
Specialized Hi Lo disc, sealed cartridge bearings, 15mm thru-axle, 32h
Rear Hub
Specialized Hi Lo disc, double-sealed cartridge bearings, QR, 32h
Rims
Roval 29, alloy disc, 26mm wide, 32h
Spokes
DT Industry Stainless, 3X front/rear 2.0
Tires
S-Works Fast Trak, 2Bliss Ready, 29x2.0"", foldable aramid bead, 120 TPI
Brakes
Brakes
Formula C1, alloy caliper, metallic pad, 15.5""/17.5"": 160mm, 19""/21"": 180mm rotor
Brake Levers
Formula C1, hydraulic disc, tooled reach adj.
Cockpit
Stem
Specialized XC, 3D forged alloy, 4-bolt, 6-degree rise, 31.8mm clamp
Handlebar
Specialized XC, flat bar, 2014 butted alloy, 700mm wide, 8-degree backsweep, 31.8mm
Grips
Specialized Sip Grip, light lock-on, half-waffle aramid-infused, 15.5""/17.5"": regular, 19""/21"": XL thickness
Headset
1-1/8 and 1-1/2"" threadless, Campy style upper with 1-1/2"" lower, cartridge bearings
Seat
Saddle
Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm
Seatpost
Specialized 2014 butted alloy, single bolt setback, 27.2mm, 15.5/17.5"" 350mm, Others: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 19" | 21" | 23" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.52 mm | 1.48 mm | 1.44 mm | 1.44 mm |
| Bottom Bracket Height | 304 mm | 304 mm | 304 mm | 304 mm | 304 mm |
| Front Center | 624 mm | 643 mm | 669 mm | 694 mm | 714 mm |
| Rake | 47 mm | 44 mm | 46 mm | 45 mm | 46 mm |
| Trail | 76 mm | 79 mm | 77 mm | 78 mm | 77 mm |
| Stack | 590 mm | 610 mm | 624 mm | 638 mm | 657 mm |
| Reach | 387 mm | 402 mm | 422 mm | 443 mm | 457 mm |
| Top Tube Length | 564 mm | 584 mm | 609 mm | 634 mm | 654 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 394 mm | 445 mm | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 90 mm | 100 mm | 115 mm | 130 mm | 150 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1045 mm | 1064 mm | 1090 mm | 1115 mm | 1136 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 752 mm | 790 mm | 820 mm | 854 mm | 887 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
Stumpjumper Comp 29 completes the Specialized Stumpjumper model. 352 bikes variations carry this model name so far. Check out the entire range from 2014 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The fork installed on this bike is the RockShox Reba model. The travel on this model is 90mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The wheels on Stumpjumper Comp 29 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Stumpjumper Comp 29 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
