Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 26" -
Travel Front 90mm -
Fork RockShox Reba
-
Groupset X9, X7 -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 8m carbon, FACT IS construction, tapered HT, carbon PF30 BB, DMD, hollow carbon dropouts, replaceable alloy derailleur hanger
Suspension Fork
RockShox Reba RL, tapered alloy steerer, LO and reb adj. standard drop-outs, 90mm travel
Drivetrain
Rear Derailleur
SRAM X9, 10-speed, mid cage
Front Derailleur
SRAM X7, 10-speed, S3 direct mount for DMD, bottom-pull
Shift Levers
SRAM X7, 10-speed, aluminum trigger, w/MatchMaker clamps
Cassette
SRAM PG-1030, 10-speed, 11-36t
Crank
Custom SRAM S-1250, 7050 alloy arms, 10-speed XC double, PF30 spindle, 15.5"": 170mm, Others: 175mm
Bottom Bracket
SRAM PF30, OS press-in bearing, sealed cartridge
Chain
KMC X-10, 10-speed, w/ reusable Missing Link, nickel plates
Pedals
Resin Test Ride Pedals with toe clips, CEN std.
Wheels
Front Hub
Specialized Hi Lo disc, laser-etched logo, OS 28 end caps, sealed cartridge bearing, RWS, 28h
Rear Hub
Specialized Hi Lo disc, laser-etched logo, double-sealed cartridge bearing, QR, 32h
Rims
Custom DT Swiss X420SL, 24mm w/ eyelets, 28/32h
Spokes
DT Swiss Industry 2.0, (14g) stainless
Tires
S-Works Fast Trak, 120 TPI, 2Bliss ready aramid bead, dual-compound, 26x2.0""
Brakes
Brakes
Custom Avid Elixir 7 SL, hydraulic disc, alloy backed semi-metallic pad, 160mm HS-1 rotor
Brake Levers
Custom Avid Elixir R SL hydraulic, tool-less reach adj. w/MatchMaker clamps
Cockpit
Stem
Specialized XC, 3D forged alloy, 4-bolt, 31.8mm clamp, adjustable rise, S: 75mm, M: 90mm, L: 105mm, XL: 105mm
Handlebar
Specialized XC flat, 2014 butted alloy, 680mm wide, 8º back sweep, 31.8mm
Grips
Specialized lock-on, S/M: Grappler, Others: Grappler XL
Headset
1-1/8 and 1-1/2"" Threadless, Campy style upper with 1-1/2"" lower bearing for tapered integrated HT, cartridge bearings
Seat
Saddle
Specialized Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm width
Seatpost
2014 butted alloy, single bolt setback, 27.2mm, 350mm 15.5/17.5"", 400mm 19/21""
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 19" | 21" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.44 mm | 1.38 mm | 1.36 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm |
| Front Center | 612 mm | 648 mm | 673 mm | 699 mm |
| Rake | 38 mm | 36 mm | 39 mm | 39 mm |
| Trail | 81 mm | 83 mm | 80 mm | 80 mm |
| Stack | 566 mm | 585 mm | 590 mm | 608 mm |
| Reach | 374 mm | 406 mm | 427 mm | 446 mm |
| Top Tube Length | 549 mm | 584 mm | 609 mm | 634 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm | 165 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1027 mm | 1063 mm | 1089 mm | 1115 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 732 mm | 761 mm | 794 mm | 829 mm |
| Wheels | 26" | 26" | 26" | 26" |
Model Overview
Stumpjumper Comp Carbon belongs to the Specialized Stumpjumper model. Specialized launched 352 bikes of this model so far. Take a sneak peek at all Specialized Stumpjumper bikes models from 2012, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
This bike has the RockShox Reba fork installed. The fork’s travel is 90mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
Stumpjumper Comp Carbon has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
When it comes to wheels, the Stumpjumper Comp Carbon bike is equipped with the 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Stumpjumper Comp Carbon comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
