Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 80mm -
Fork Fox
-
Groupset X0, X7 -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M5 fully manipulated alloy, 29"" geometry, tapered HT, PF30 BB, PM 140mm rear brake, 135mm dropouts, replaceable derailleur hanger
Suspension Fork
Fox Float 29 Evolution RL, air spring, tapered steerer, LO and reb adj. S: 80mm travel (straight 1-1/8"" steerer), Others: 100mm travel
Drivetrain
Rear Derailleur
SRAM X0, 10-speed, short cage
Front Derailleur
e. thirteen XCX chain guide, seat tube mounted
Shift Levers
SRAM X7, 10-speed, aluminum trigger, w/MatchMaker clamps
Cassette
SRAM PG-1030, 10-speed, 11-36t
Crank
Custom SRAM S-1250, 7050 alloy arms, 33T single ring, PF30 spindle, 15.5"": 170mm, Others: 175mm
Bottom Bracket
SRAM PF30, OS press-in bearing, sealed cartridge
Chain
KMC X-10, 10-speed, w/ reusable Missing Link, nickel plates
Pedals
Resin Test Ride Pedals with toe clips, CEN std.
Wheels
Front Hub
Specialized Hi Lo disc, laser-etched logo, OS 24 end caps, sealed cartridge bearing, RWS, 32h
Rear Hub
Specialized Hi Lo disc, laser-etched logo, double-sealed cartridge bearing, QR, 32h
Rims
Roval 29, 26mm w/ eyelets, 32h
Spokes
DT Swiss Industry 2.0, (14g) stainless
Tires
S-Works Purgatory, 120 TPI, 2Bliss ready aramid bead, dual-compound, 29x2.2""
Brakes
Brakes
Custom Avid Elixir 7 SL, hydraulic disc, alloy backed semi-metallic pad, 180mm HS-1 rotor
Brake Levers
Custom Avid Elixir R SL hydraulic, tool-less reach adj. w/MatchMaker clamps
Cockpit
Stem
Specialized XC, 3D forged alloy, 4-bolt, 31.8mm clamp, adjustable rise, S: 75mm, M: 90mm, L: 105mm, XL/XXL: 105mm
Handlebar
Specialized XC Mini-Riser, 7050 butted alloy, 720mm wide, 10mm rise, 10º backsweep, 6º upsweep, 31.8mm
Grips
Specialized lock-on, S/M: Grappler, Others: Grappler XL
Headset
1-1/8 threadless, Campy style upper with 1-1/2"" lower bearing for tapered integrated HT, cartridge bearings
Seat
Saddle
Specialized Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm width
Seatpost
2014 butted alloy, single bolt setback, 27.2mm, 350mm 15.5/17.5""
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 19" | 21" | 23" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.52 mm | 1.48 mm | 1.44 mm | 1.44 mm |
| Bottom Bracket Height | 304 mm | 304 mm | 304 mm | 304 mm | 304 mm |
| Front Center | 624 mm | 643 mm | 669 mm | 694 mm | 714 mm |
| Rake | 47 mm | 44 mm | 46 mm | 45 mm | 46 mm |
| Trail | 76 mm | 79 mm | 77 mm | 78 mm | 77 mm |
| Stack | 590 mm | 610 mm | 624 mm | 638 mm | 657 mm |
| Reach | 387 mm | 402 mm | 422 mm | 443 mm | 457 mm |
| Top Tube Length | 564 mm | 584 mm | 609 mm | 634 mm | 654 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 394 mm | 445 mm | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 90 mm | 100 mm | 115 mm | 130 mm | 150 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1045 mm | 1064 mm | 1090 mm | 1115 mm | 1136 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 752 mm | 790 mm | 820 mm | 854 mm | 887 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
Stumpjumper EVO 29 completes the Specialized Stumpjumper model. Specialized released 352 bikes variations of this model so far. Check out the entire range from 2012 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Stumpjumper EVO 29 components
Fork
The fork installed on this bike is the Fox model. The travel on this model is 80mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The Stumpjumper EVO 29 2012 bike is equipped with 29″ carbon wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Stumpjumper EVO 29 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
