Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 130mm -
Fork RockShox Reba
-
Groupset X9, SLX -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Stumpjumper FSR M5 manipulated alloy 29er frame, tapered integrated HT, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm travel
Suspension Fork
Rock Shox Reba SL 29 for Specialized, 120mm of travel, 45mm offset, air spring, alloy tapered steerer, compression and rebound adj. w/ LO
Rear Shock
Fox Triad, custom on-the-fly 3-position switch 1) lock out 2) Open 3) ProPedal pedal assisting damping, rebound adj. 7.875x1.8""
Drivetrain
Rear Derailleur
SRAM X-9, 9-speed long cage
Front Derailleur
Shimano M660 SLX, DMD, top swing, dual pull
Shift Levers
SRAM X-7, aluminum trigger
Cassette
Shimano HG61, 9-speed, 12-36t
Crank
Custom Shimano FC-M542, 175mm
Bottom Bracket
Custom Shimano integrated
Chain
SRAM PC-971, 9-speed w/Power Link
Pedals
None
Wheels
Front Hub
Hi-Lo disc, 20mm thru-axle, 32h
Rear Hub
Custom Shimano M525 SL, alloy QR, 32h
Rims
Custom DT Swiss 520SL, 29"", 26mm wide, sleeved w/eyelets, 32h
Spokes
DT Swiss 1.8mm stainless
Tires
S-Works Eskar, 29x2.3"", 120 TPI, tubeless ready aramid bead, dual compound
Brakes
Brakes
Custom Avid Elixir R SL, alloy backed semi-met pads, S/M: 185mm, L/XL: 200mm rotor
Brake Levers
Custom Avid Elixir R SL Hydraulic, tool-less adj. reach
Cockpit
Stem
3D forged alloy, adjustable rise, 31.8mm clamp
Handlebar
Specialized XC flat, 2014 butted alloy, 680mm wide, 8 degree backsweep,
Grips
Specialized waffle lock on grip (S/M) Specialized Thick lock on grip (L/XL)
Headset
1-1/8 and 1.5"" Threadless, Campy style upper with 1.5"" lower cartridge bearing
Seat
Saddle
Specialized Format, hollow Cr-Mo rails, SL foam, M: 130mm L/XXL:143mm
Seatpost
2014 butted alloy, single bolt setback, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.36 mm | 1.33 mm | 1.3 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm |
| Stack | 585 mm | 603 mm | 622 mm | 631 mm |
| Reach | 420 mm | 445 mm | 467 mm | 487 mm |
| Top Tube Length | 581 mm | 611 mm | 639 mm | 659 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 445 mm | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 160 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1118 mm | 1150 mm | 1179 mm | 1199 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 740 mm | 756 mm | 763 mm | 757 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Stumpjumper FSR Comp 29 belongs to the Specialized Stumpjumper model. 352 bikes variations carry this model name so far. Take a sneak peek at all Specialized Stumpjumper bikes models from 2010, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Stumpjumper FSR Comp 29 components
Fork
Specialized Stumpjumper FSR Comp 29 2010 bike is equipped with the RockShox Reba fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork on this bike is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
Specialized Stumpjumper FSR Comp 29 bike has the Fox Triad model installed, and has a travel of 130mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The wheels on Stumpjumper FSR Comp 29 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Stumpjumper FSR Comp 29 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
