Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Revelation RC
-
Groupset X9, X7 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FACT 8m carbon front triangle, FACT IS construction, tapered HT, OS BB, M5 aluminum rear triangle, sealed cartridge bearing pivots, replaceable derailleur hanger, 140mm travel
Suspension Fork
RockShox Revelation RL, Motion Control damper, Dual Air, alloy steerer, comp and reb adj. w/LO, 140mm travel
Rear Shock
Custom Fox Triad II, custom on-the-fly 3-position switch 1) lock out 2) Open 3) ProPedal pedal assisting damping, rebound adj. 7.75x1.9""
Drivetrain
Rear Derailleur
SRAM X.9, 10-speed, mid cage
Front Derailleur
SRAM X.7, 10-speed, S1 direct mount for DMD, bottom pull
Shift Levers
SRAM X.7, 10-speed, aluminum trigger
Cassette
Shimano HG81, 10-speed, 11-36t
Crank
Custom SRAM S-1250, 7050 alloy arms, 10-speed XC Trail double, GXP spindle, S: 170mm, others: 175mm
Bottom Bracket
Custom SRAM GXP, 84.5mm
Chain
KMC X10, 10-speed, w/ reuseable Missing Link, nickel plates
Pedals
Resin Test Ride Pedals with toe clips, CEN std.
Wheels
Front Hub
Specialized Hi Lo disc, laser-etched logo, OS 28 end caps, sealed cartridge bearing, RWS, 28h
Rear Hub
Specialized Hi Lo disc, laser-etched logo, double sealed cartridge bearing, QR, 32h
Rims
Custom DT Swiss X420SL, 24mm w/ eyelets, 28/32h
Spokes
DT Swiss Champion 1.8mm (15g) stainless
Tires
S-Works Purgatory, 120 TPI, 2Bliss ready aramid bead, dual compound, 26x2.2""
Brakes
Brakes
Custom Avid Elixir R SL, hydraulic disc, tool-less reach adjust, alloy backed semi-metallic pads, stainless hardware, S/M: 185mm, L/XL: 203mm rotor
Brake Levers
Custom Avid Elixir R SL hydraulic, tool-less reach adj.
Cockpit
Stem
Specialized XC, 3D forged alloy, 4-bolt, 31.8mm clamp, adjustable rise
Handlebar
Specialized XC low-rise bar, 2014 butted alloy, 680mm wide, 8 degree back sweep, 6 degree up, 31.8mm
Grips
Specialized lock-on, S/M: Grappler, Other: Rocca
Headset
1-1/8 and 1.5"" Threadless, Campy style upper with 1.5"" lower, cartridge bearings
Seat
Saddle
Specialized BG Henge Comp, hollow Cr-Mo rails, 143mm width
Seatpost
2014 butted alloy, single bolt setback, 30.9mm, S/M: 350mm, others: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.37 mm | 1.31 mm | 1.27 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Stack | 571 mm | 590 mm | 600 mm | 609 mm |
| Reach | 404 mm | 430 mm | 458 mm | 480 mm |
| Top Tube Length | 562 mm | 593 mm | 623 mm | 648 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 406 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 118 mm | 138 mm | 148 mm | 158 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1089 mm | 1122 mm | 1153 mm | 1179 mm |
| Bottom Bracket Drop | 8 mm | 8 mm | 8 mm | 8 mm |
| Standover Height | 743 mm | 749 mm | 759 mm | 783 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Stumpjumper FSR Comp Carbon completes the Specialized Stumpjumper model. 352 bikes variations carry this model name so far. Check out the entire range from 2011 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
Specialized Stumpjumper FSR Comp Carbon 2011 bike is equipped with the RockShox Revelation RC fork, and has 140mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
The Stumpjumper FSR Comp Carbon has a rear shock with a travel of 140mm. The model Custom Fox Triad II is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When it comes to wheels, the Stumpjumper FSR Comp Carbon bike is equipped with the 26″ aluminum model. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
When you want to stop the bike in time, the brakes are vital. The Stumpjumper FSR Comp Carbon has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Specialized Stumpjumper FSR Comp Carbon bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
