Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 140mm -
Travel Rear 140mm -
Fork Fox
-
Groupset XTR, X7 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M5 manipulated alloy w/ ORE TT/DT, sealed cartridge bearing pivots, replaceable derailleur hanger, 140mm travel
Suspension Fork
Fox F140 RL, air spring, alloy steerer, reb adj. LO, standard drop-outs, 140mm travel
Rear Shock
Specialized/Fox Brain Shock w/ remote Trail Tune inertia valve, Brain Fade and rebound adj. 7.75x1.9"", integrated cartridge bearing shock mount
Drivetrain
Rear Derailleur
Shimano RD-M980 XTR Shadow, 10-speed, mid cage
Front Derailleur
SRAM X.7, 10-speed, S1 direct mount for DMD, bottom pull
Shift Levers
Shimano SL-M660-10R SLX, 10-speed, trigger
Cassette
Shimano HG81, 10-speed, 11-36t
Crank
Custom SRAM Carbon S-2200, 10-speed XC Trail double, GXP spindle, removeable spider, S: 170mm, others: 175mm
Bottom Bracket
SRAM GXP, outboard bearing
Chain
KMC X10, 10-speed, w/ reuseable Missing Link, nickel plates
Pedals
Resin Test Ride Pedals with toe clips, CEN std.
Wheels
Front Hub
Specialized Hi Lo disc, laser-etched logo, OS 24 end caps, sealed cartridge bearing, RWS, 28h
Rear Hub
Specialized Hi Lo disc, laser-etched logo, double sealed cartridge bearing, QR, 32h
Rims
Custom DT Swiss X420SL, 24mm w/ eyelets, 28/32h
Spokes
DT Swiss Champion 1.8mm (15g) stainless
Tires
S-Works Purgatory, 120 TPI, 2Bliss ready aramid bead, dual compound, 26x2.2""
Brakes
Brakes
Custom Avid Elixir R SL, hydraulic disc, tool-less reach adjust, alloy backed semi-metallic pads, stainless hardware, S/M: 185mm, L/XL/XXL: 203mm rotor
Brake Levers
Custom Avid Elixir R SL hydraulic, tool-less reach adj.
Cockpit
Stem
Specialized XC, 3D forged alloy, 4-bolt, 31.8mm clamp, adjustable rise
Handlebar
Specialized XC-low rise bar, 7050 butted alloy, 680mm wide, 8 degree back sweep, 6 degree up, 31.8mm
Grips
Specialized lock-on, S/M: Grappler, Other: Rocca
Headset
1 1/8"" upper and lower campy style cartridge bearings for integrated alloy HT
Seat
Saddle
Specialized BG Henge Comp, hollow Cr-Mo rails, 143mm width
Seatpost
2014 butted alloy, single bolt setback, 30.9mm, S/M: 350mm, others: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.37 mm | 1.31 mm | 1.27 mm | 1.21 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm | 335 mm |
| Stack | 571 mm | 590 mm | 600 mm | 609 mm | 609 mm |
| Reach | 404 mm | 430 mm | 458 mm | 480 mm | 503 mm |
| Top Tube Length | 562 mm | 593 mm | 623 mm | 648 mm | 671 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 406 mm | 445 mm | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 118 mm | 138 mm | 148 mm | 158 mm | 158 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1089 mm | 1122 mm | 1153 mm | 1179 mm | 1202 mm |
| Bottom Bracket Drop | 8 mm | 8 mm | 8 mm | 8 mm | 8 mm |
| Standover Height | 747 mm | 752 mm | 759 mm | 772 mm | 776 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
Model Overview
Stumpjumper FSR Elite completes the Specialized Stumpjumper model. There are 352 bikes that carry this model name. You can get a glimpse at all models from 2011, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
Specialized Stumpjumper FSR Elite 2011 bike is equipped with the Fox fork, and has 140mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
Stumpjumper FSR Elite has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
Specialized Stumpjumper FSR Elite bike has the Specialized/Fox Brain Shock w/ remote Trail Tune inertia valve model installed, and has a travel of 140mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When leaving the production line, the Stumpjumper FSR Elite model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The Stumpjumper FSR Elite has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
