Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Rear 130mm -
Groupset SLX -
Suspension Full
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Stumpjumper FSR M5 manipulated alloy 29er frame, tapered integrated HT, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm travel
Rear Shock
Specialized/Fox AFR Brain Shock w/ remote Trail Tune inertia valve, rebound adj. and Brain Fade, 7.875x1.8"" Integrated cartridge bearing shock mount.
Drivetrain
Front Derailleur
Shimano M660 SLX, DMD, top swing, dual pull
Cockpit
Headset
1-1/8 and 1.5"" Threadless, Campy style upper with 1.5"" lower cartridge bearing
Seat
Seatpost
2014 butted alloy, single bolt setback, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.36 mm | 1.33 mm | 1.3 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm |
| Stack | 585 mm | 603 mm | 622 mm | 631 mm |
| Reach | 420 mm | 445 mm | 467 mm | 487 mm |
| Top Tube Length | 581 mm | 611 mm | 639 mm | 659 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 445 mm | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 160 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1118 mm | 1150 mm | 1179 mm | 1199 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 740 mm | 756 mm | 763 mm | 757 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
Stumpjumper FSR Expert 29 Frame belongs to the Specialized Stumpjumper model. Specialized launched 352 frames of this model so far. Take a sneak peek at all Specialized Stumpjumper frames models from 2010, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail frames
According to our math, the average price for a trustworthy Trail frame is 1736$. However, this doesn’t mean that if you spend less money on a Trail frame, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the frame and its components before buying it to ensure you don’t pay too much.
Stumpjumper FSR Expert 29 Frame components
Rear Shock
From the factory, it comes with the Specialized/Fox AFR Brain Shock w/ remote rear shock model, which has a travel of 130mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
