Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox
-
Groupset X0, SLX -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Stumpjumper FSR FACT 9M carbon main triangle, Az1 construction, M5 alloy SS/CS with Brain mount, DMD Direct Mount F.Der, full cartridge bearing pivots, 120mm travel
Suspension Fork
Fox F120RLC, 120mm, compression and rebound adj. w/ LO, alloy steerer
Rear Shock
Specialized AFR Brain Shock w/ remote Trail Tune inertia valve, rebound adj. and Brain Fade, 7.25x1.75""
Drivetrain
Rear Derailleur
SRAM X.0 9-speed, mid cage
Front Derailleur
Shimano M660 SLX, DMD, top swing, dual pull
Shift Levers
SRAM X-9, trigger
Cassette
Shimano HG61, 9-speed, 11-34t
Crank
Custom Shimano FC-M762, 2pc. S: 170mm, others: 175mm
Bottom Bracket
Custom Shimano M762
Chain
SRAM PC-971, 9-speed w/Power Link
Pedals
None
Wheels
Front Hub
Specialized Hi Lo disc, CNC flange, sealed cartridge bearing, 9mm DT RWS, alloy QR, 28h
Rear Hub
Custom DT Swiss 370 w/ DT RWS QR, 32h
Rims
Custom DT Swiss X420SL, 24mm w/ eyelets, 28/32h
Spokes
DT Swiss Competition 1.8/1.6mm stainless, black, alloy nipples
Tires
S-Works The Captain, 26x2.2"", 120 TPI, Aramid bead, dual compound, tubeless ready
Brakes
Brakes
Custom Avid Elixir R Carbon SL, Carbon lever, SS hardware, alloy backed organic pads, S/M: 185mm, L/XL: 203mm rotor
Brake Levers
Custom Avid Elixir R Carbon SL Hydraulic, tool-less adj. reach
Cockpit
Stem
Specialized adjustable rise, 31.8mm clamp, 3D forged w/ CNC finish
Handlebar
Specialized XC low rise 31.8mm bar, 2014 butted alloy, 6 degree up, 8 degree backsweep, 640mm wide
Grips
Specialized thin lock on grip (S/M) Specialized Thick lock on grip (L/XL)
Headset
1-1/8"" Threadless, Campy style upper and lower cartridge bearing
Seat
Saddle
Specialized Format, hollow Cr-Mo rails, SL foam, S/M: 130mm L/XL:143mm
Seatpost
2014 butted alloy, single-bolt setback, 30.9x350/400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm | 335 mm |
| Top Tube Length | 562 mm | 593 mm | 631 mm | 651 mm | 671 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 406 mm | 445 mm | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm | 160 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1090 mm | 1121 mm | 1161 mm | 1183 mm | 1203 mm |
| Bottom Bracket Drop | 8 mm | 8 mm | 8 mm | 8 mm | 8 mm |
| Standover Height | 727 mm | 734 mm | 761 mm | 770 mm | 784 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
Model Overview
Stumpjumper FSR Expert Carbon completes the Specialized Stumpjumper model. There are 352 bikes that carry this model name. You can get a glimpse at all models from 2009, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
Specialized Stumpjumper FSR Expert Carbon 2009 bike is equipped with the Fox fork, and has 120mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
Stumpjumper FSR Expert Carbon has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
The Stumpjumper FSR Expert Carbon has a rear shock with a travel of 120mm. The model Specialized AFR Brain Shock w/ remote Trail Tune inertia valve is the one installed in this bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on Stumpjumper FSR Expert Carbon are the 26″ aluminum type. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized Stumpjumper FSR Expert Carbon is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
