Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 135mm -
Fork RockShox Revelation RC
-
Groupset X0, X7 -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M5 hydroformed tubing, 29"" EVO geometry, tapered HT, PF30 BB, ISCG ’05, Command Post routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 135mm travel
Suspension Fork
RockShox Revelation RL 29, DNA Damper, LO and reb adj. tapered steerer, 20mm dropout, 140mm
Rear Shock
Fox RP23 Adaptive Logic with AUTOSAG, Kashima coating, rebound adj. separate climbing setting and custom 3-position open comp adj. 197x46mm
Drivetrain
Rear Derailleur
SRAM X0, 10-speed, mid cage
Front Derailleur
SRAM X7, 10-speed, S3 direct mount for DMD, bottom-pull
Shift Levers
SRAM X7, 10-speed, trigger
Cassette
SRAM PG-1050, 10-speed, 11-36t
Crank
Custom SRAM carbon S-2200, 10-speed XC Trail double, PF30 spindle, removable spider, S: 170mm, Others: 175mm
Bottom Bracket
SRAM PF30, OS press-in bearing, sealed cartridge
Chain
KMC X-10, 10-speed, w/ reusable Missing Link, nickel plates
Pedals
Resin Test Ride Pedals with toe clips, CEN std.
Wheels
Front Hub
Roval Traverse 29, 20mm thru-axle caps, 32h
Rear Hub
Roval Traverse 29 142+, 12mm thru-axle, 32h
Rims
Roval Traverse 29, alloy disc, 28mm, 32h
Spokes
DT Swiss Super Comp, 2.0/1.65/1.8 stainless
Tires
Specialized Purgatory Control, 60 TPI, 2Bliss ready aramid bead, dual-compound, 29x2.2""
Brakes
Brakes
Custom Formula The One R, hydraulic disc, tool-less FCS and reach adjust, metallic pad, SRAM compatible MiXmaster shifter mounts, S/M:180mm rotor, Others: 203mm rotor
Brake Levers
Custom Formula The One R hydraulic, tool-less reach adj.
Cockpit
Stem
Specialized XC, 3D forged alloy, 4-bolt, 31.8mm clamp, adjustable rise, S/M: 60mm, L:75, XL:90mm, XXL: 105
Handlebar
Specialized XC Mini-Riser, 7050 butted alloy, 720mm wide, 10mm rise, 10º backsweep, 6º upsweep, 31.8mm
Grips
Specialized lock-on, S/M: Grappler, Others: Grappler XL
Headset
1-1/8 and 1-1/2"" Threadless, Campy style upper with 1-1/2"" lower, cartridge bearings
Seat
Saddle
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm width
Seatpost
Specialized Command Post BlackLite, 3 position, adjustable height w/air spring, remote operated, single bolt head 30.9mm, S:100mm travel, Others: 125mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.53 mm | 1.48 mm | 1.45 mm | 1.46 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 674 mm | 703 mm | 730 mm | 758 mm | 781 mm |
| Rake | 47 mm | 47 mm | 46 mm | 46 mm | 46 mm |
| Trail | 101 mm | 101 mm | 102 mm | 102 mm | 102 mm |
| Stack | 615 mm | 625 mm | 639 mm | 657 mm | 681 mm |
| Reach | 383 mm | 409 mm | 431 mm | 452 mm | 465 mm |
| Top Tube Length | 563 mm | 592 mm | 618 mm | 644 mm | 664 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 396 mm | 430 mm | 468 mm | 523 mm | 565 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 145 mm | 170 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1122 mm | 1152 mm | 1179 mm | 1207 mm | 1230 mm |
| Bottom Bracket Drop | 37 mm | 37 mm | 37 mm | 37 mm | 37 mm |
| Standover Height | 746 mm | 737 mm | 746 mm | 760 mm | 775 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
Stumpjumper FSR Expert EVO 29 is part of the Specialized Stumpjumper model. There are 352 bikes that carry this model name. Check out the entire range from 2012 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The RockShox Revelation RC is included from the factory. It has a travel distance of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the Fox RP23 Adaptive Logic with AUTOSAG rear shock model, which has a travel of 135mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When leaving the production line, the Stumpjumper FSR Expert EVO 29 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Specialized Stumpjumper FSR Expert EVO 29 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Dropper post
Specialized Stumpjumper FSR Expert EVO 29 comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
