Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Groupset X0, XT -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Stumpjumper FSR FACT 9M carbon main triangle, Az1 construction, M5 alloy SS/CS with Brain mount, DMD Direct Mount F.Der, full cartridge bearing pivots, 120mm travel
Suspension Fork
Specialized Future Shock S120, 120mm travel, single sided air spring and damper, Trail Tune, Brain Fade, rebound adj. carbon 1-1/8"" to 1.5"" steerer
Rear Shock
Specialized AFR Brain Shock w/ remote Trail Tune inertia valve, rebound adj. and Brain Fade, 7.25x1.75""
Drivetrain
Rear Derailleur
SRAM X-0, 9-speed, mid cage
Front Derailleur
Shimano M770 XT, DMD, top swing, dual pull
Shift Levers
SRAM X-0, carbon/aluminum 9-speed trigger
Cassette
Shimano M770 XT, 9-speed, 11-34t
Crank
Shimano FC-M770 XT, 2pc. S: 170mm, others: 175mm
Bottom Bracket
Shimano M-770 XT
Chain
SRAM PC-971, 9-speed w/Power Link
Pedals
None
Wheels
Front Hub
Specialized Hi Lo disc, CNC flange, sealed cartridge bearing, Oversized end caps, 9mm DT RWS, alloy QR, 28h
Rear Hub
Custom DT Swiss 280S w/ Star Rachet, alloy freehub w/ DT RWS, 10mm alloy QR, 32h
Rims
DT Swiss XR 4.2D, 24mm w/ eyelets, 28/32h
Spokes
DT Swiss Super Comp 2.0/1.7/1.8mm butted stainless, black, alloy nipples
Tires
S-Works The Captain Control, 26x2.2"", 120 TPI, Aramid bead, dual compound, tubeless ready
Brakes
Brakes
Custom Avid Ultimate SL, alloy backed organic pads, alloy caliper, magnesium lever body w/ carbon blade, SS hardware package, S/M: 185mm, L/XL: 203mm rotor
Brake Levers
Custom Avid Ultimate SL Hydraulic
Cockpit
Stem
Specialized adjustable rise, 31.8mm clamp, 3D forged w/ CNC finish
Handlebar
Specialized XC low rise 31.8mm bar, 2014 butted alloy, 6 degree up, 8 degree backsweep, 640mm wide
Grips
Specialized thin lock on grip (S/M) Specialized Thick lock on grip (L/XL)
Headset
1-1/8"" Threadless, Campy style upper and OS lower cartridge bearing
Seat
Saddle
Specialized Format, Ti rails, SL foam, S/M: 130mm L/XL:143mm
Seatpost
Thomson Elite Setback w/ 12 degree clamp, S/M: 367mm L/XL: 410mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Top Tube Length | 562 mm | 596 mm | 631 mm | 651 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 406 mm | 444 mm | 482 mm | 533 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 128 mm | 148 mm | 168 mm | 188 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1091 mm | 1127 mm | 1164 mm | 1186 mm |
| Bottom Bracket Drop | 8 mm | 8 mm | 8 mm | 8 mm |
| Standover Height | 711 mm | 734 mm | 744 mm | 770 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Stumpjumper FSR Pro Carbon is a Specialized Stumpjumper model. 352 bikes variations carry this model name so far. You can get a glimpse at all models from 2009, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Stumpjumper FSR Pro Carbon components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Rear Shock
The shock that’s installed on this bike is Specialized AFR Brain Shock w/ remote Trail Tune inertia valve, with a travel distance of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Stumpjumper FSR Pro Carbon are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
When you want to stop the bike in time, the brakes are vital. The Stumpjumper FSR Pro Carbon has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
